Dvk521 Expansion Board 7inch Lcd Touch Screen For Cubieboard1 Cortex-a8

US $88.00

Hong Kong, China
Jan 29th

Open on mobile:
QR code

Welcome to our store! Description DVK521 is an expansion board designed for Cubieboard, integrates various components and interfaces for connecting external accessory boards. It’s ideal for Cubieboard evaluation and development. Cubieboard socket OV7670 interface: for connecting OV7670 Camera Module 8I/Os interface: easily connects to modules controlled by I/Os, such as 8 Push Buttons SPI interface: easily connects to SPI modules such as AT45DBXX Dataflash, etc. I2C interface: easily connects to I2C modules such as PCF8574 Expansion Module, PCF8563 RTC Module, etc. USB interface: USB TO UART, convenient for debugging VGA interface: for connecting VGA display Module Capacitive touch screen socket: for connecting capacitive touch screen using I2C interface 7inch LCD interface: for connecting 7inch LCD ONE-WIRE interface: easily connects to ONE-WIRE devices (TO-92 package), such as temperature sensor (DS18B20), electronic registration number (DS2401), etc. UART interface (PL2303TA): connects to the UART interface of Cubieboard Cubieboard Ext Ports 5V/3.3 V power input/output: usually used as power output, also common-grounding with other user board Power indicator User LEDs Buzzer User Keys Joystick: five positions PL2303TA: onboard USB TO UART convertor 12M crystal: for PL2303TA Joystick jumper User Keysjumper ONE-WIRE jumper Buzzer jumper User LEDs jumper Prototyping area: can be used to place user components for experiments For jumpers above: short the jumper to connect to I/Os used in example code open the jumper to connect to other custom pins via jumper wires Development Resources The User Guide CD includes development resources listed as follow: User manual Development environment setup guide Kernel porting and configuration guide Drivers porting and configuration guide Schematic (PDF) Demo code drivers and API testing source code Linux kernel driver source code, and the high-level API source code based on Linux Pre-configured Cubieboard image ubuntu based on ARM chips, just burn it into SD card, it’s ready to run Related documentations and software Examples Kernel/Peripheral Interface Linux AT24CXX EEPROM I2C Y FM24CXX FRAM I2C Y AT45DBXX DATAFLASH SPI Y DS18B20 Temperature sensor 1-WIRE Y PL2303 USB TO UART UART Y 7inch multi-color LCD LCD Y Capacitive touch screen I2C Y OV7670 Camera Camera Y VGA VGA Y Buzzer I/Os Y Joystick I/Os Y User keys I/Os Y LED I/Os Y For Some documents and guides, please visit below website: http://docs.cubieboard.org/tutorials/dvk521/start http://www.waveshare.net/shop/Cubieboard-Package-B.htm Package List: 1 x DVK521 1 x 7inch Capacitive Touch LCD 1 x LCD screws pack 1 x 40-pin FFC 1 x 4-pin FFC 1 x OV7670 Camera Board 1 x VGA PS2 Board 1 x AT45DBXX DataFlash Board 1 x FM24CLXX FRAM Board 1 x 8 Push Buttons 1 x DS18B20 1 x 4-pin 2-pin wires pack 1 x USB type A plug to mini-B plug cable 1 x Ethernet Cable Payment 1.We accept PayPal only. 2.Payment must be received within 7 business days of auction closing.,or a unpaid case will be opened. Delivery details 1.Standard shipping carrier is ePacket with tracking code for United States address,delivery within 7-14 busienss days. 2.For outside US address,standard shipping carrier is Hong Kong Post without tracking code,delivery within 25-30 business days.We provide a free tracking for order above 45USD.Please contact us if you want to add a tracking code for small orders. 3.Express shipping like DHL,Fedex,UPS,TNT is also avaiable if you are willing to pay extra.DHL is our standard shipping carrier for Expedited shipping,please contact us if you want a different carrier. Terms of sales 1.Customs duties or taxes are buyer's resposibility for all of the listings.Please check with your local customs office if you have any doubts. 2.Please confirm you are putting a correct and complete shipping address here.You are resposible for extra charge if your package been returned because of wrong address.If packages return because of wrong address,you will have to bear extra cost of shipping. About us 1.We are always here for you,offering friendly, comprehensive customer service every step of the way. Please follow the good eBay practice to contact us if any doubts and problems.We sincerely hope our item and customer service can give you the BEST BUYING EXPERIENCE on eBay. 2.We believe nothing can solve problems but communication.Please contact our team via ebay message first before leaving any non-positive feedbacks if you feel unhappy here. Contact us 1.We are always here for you,offering friendly, comprehensive customer service every step of the way. Please follow the good eBay practice to contact us if any doubts and problems.We sincerely hope our item and customer service can give you the BEST BUYING EXPERIENCE on eBay. 2.We believe nothing can solve problems but communication.Please contact our team via ebay message first before leaving any non-positive feedbacks if you feel unhappy here. Engineered for professional eBay sellers! On Dec-09-14 at 09:05:33 PST, seller added the following information:
