Et120m Handheld Oscilloscope 120mhz Bandwidth With Backlight Square Wave Output

US $91.08

Shenzhen, China
Aug 28th

Open on mobile:
QR code

ET120M 120MHz Bandwidth 500MS/s Sampling Rate Colorful 2500 Waveform Storage LCD Screen with Backlight Square Wave Output Feature: 120MHz bandwidth and 500MS/s sampling rate It is not just an oscilloscope, but also has 4 speeds of square wave signal output function(1kHz,10KHz,100KHz,1MHz) Portable, hand-held, sufficient power can achieve 8 hours of battery life One-key automatic measurement of waveforms, with one X1/X10 oscilloscope probe included 12 kinds of parameter measurement, Vpp, Vrms, Vavg, Vp, Vmax, Vmin,F,T,T+,T-. Du+, Du-. Specification: Analog bandwidth: 120MHz Display: 320x240 LCD screen Display area: 50mm x 40mm/1.96x1.57'' Storage: 2500 DSO waveforms Vertical resolution: 8 bits Automatic measurement function: Vpp, Vrms, Vavg, Vp, Vmax, Vmin,F,T,T+,T-. Du+, Du- Vertical sensitivity range: x1: 50mV/div ~ 10V/div x 10: 500mV/div ~ 100V/div Vertical accuracy: ±(5%+ 0.2div) Backlight: White, brightness adjustable Impedance: x1: 1M / x10: 10M Battery: 18650 lithium battery Auto shutdown: No operation for 15 minutes Size: 124 x 80 x 35mm/4.88x3.14x1.37'' Use conditions: 0C~ +40; < 75%RH Storage conditions: -10C~ +60; < 90%RH Auto zero reference: During DC measurement Trigger level: ±3.8div (0. 1div per step) Trigger position: ± 6div (0. 1div per step) Cursor function: V, t, 1 /t Measurement Accuracy: ±(5%+ 0.2div) Non. linearity: ±1 bits Coupling method: DC/AC Division: Vertical: ±3.8 Horizontal:12 Time base range: 6ns/div ~ 50s/div Time base accuracy: ±(0.01%+0.1div) Scan mode: Auto/Single/Normal Trigger slope: Rising / Falling Record length: 12div Maximum real-time sampling rate: 500MS/s Auto configuration: Automatically set time base and vertical amplitude Packing List: 1*Oscilloscope 1*Probe 1*USB Cable 1*User Manual On Aug-28-21 at 12:57:07 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
MPN	XJX1261-52
Analog bandwidth	120MHz
Display	320x240 LCD screen
Display area	50mm x 40mm/1.96x1.57''
Storage	2500 DSO waveforms
Vertical resolution	8 bits
Vertical accuracy	±(5%+ 0.2div)
Backlight	White, brightness adjustable
Impedance	x1: 1M / x10: 10M
Battery	18650 lithium battery
Auto shutdown	No operation for 15 minutes
Size	124 x 80 x 35mm/4.88x3.14x1.37''
Use conditions	0C~ +40; < 75%RH
Storage conditions	-10C~ +60; < 90%RH
Auto zero reference	During DC measurement
Trigger level	±3.8div (0. 1div per step)
Trigger position	± 6div (0. 1div per step)
Measurement Accuracy	±(5%+ 0.2div)
Non. linearity	±1 bits
Coupling method	DC/AC
Division: Vertical	±3.8 Horizontal:12
Time base range	6ns/div ~ 50s/div
Time base accuracy	±(0.01%+0.1div)
Scan mode	Auto/Single/Normal
Trigger slope	Rising / Falling
Record length	12div
Maximum Real-Time Sampling Rate	500MS/s
Auto configuration	Automatically set time base and vertical amplitude
Brand	Unbranded
UPC	6933834694746
