Etcr2800c Multifunction Non-contact Resistance Online Tester !!new!!

US $364.50

Qingdao City, China
Jan 29th

Open on mobile:
QR code

I. Brief Introduction ETCR2000C Multifunction Non-Contact Resistance Online Tester is our company devotes ourselves to Grounding resistance test technical research’s another new high-tech product for more than ten years. Detector adopts weather fastness material manufacture, temperature resistance, cold-resistant, corrosion prevention, fire prevention. Detector’s structure is rigorous and firm, against rain, dustproof, installation and use outdoors. Non-contact measurement, safe and reliable, Ease of installation. Grounding down lead is directly through the detector perforation, Will not affect lightning protection grounding effect and the normal operation of the facilities. Ensure high-accuracy, high stability and high reliability of long time on-line monitoring outdoors, underground mine and indoors. ETCR2800C Multifunction Non-Contact Resistance Online Tester is equipped with LCD display and alarm light, which can observe grounding resistance value at any times and set the alarm critical val. Alarm light will flash when measured value is beyond pre-set critical value. Detector applies to electric transmission line pole ground connection, underground mine device ground connection, meteorological lightning protection grounding connection, petrochemical engineering ground connection, communication ground connection, rail facility ground connection, building the warehouse ground connection, electrical equipment ground connection etc.. Detector provides power supply and RS485 signal interface, and standard MODBUS-RTU communication protocol,which user can do secondary development to realize remote monitoring. ETCR2800C’s LCD shows measured value directly, also sets up Detector’s alarm critical value, and possess audible and visual alarming function, which is very suitable to Independent installation and use when it needn’t form a network. II. Technical Specifications Functions Return circuit ground resistance, metallic return connection resistance, grounding conditions on-line monitoring Power Supply 6VDC~9VDC, 50mA Max. Resistance Range 0.01?~200? Resolution 0.001? Display Range 0.00?~500? Accuracy ±2%rdg±3dgt(20°C±5°C, below70%RH) Grounding Wire Perforation Size 60mmx30mm, closed mode (60mmx4mm steel flat or external diameter?30mm electric cable) Overflow Indication When show value is beyond 500?, systems software and LCD show “OL?” sign. Connecting Line A one meter long wire (5cores shielded wire) Connection Identifier Red/brown---power supply input anode; Black--- power supply input cathode. Blue---RS485 signal anode; Grey---RS485 signal cathode; White--- analog grounding (power supply input cathode can connects with analog grounding by short circuit connection) Communication Protocol RS485 standard MODBUS-RTU communication protocol Alarm Indication Detector Audible and visual alarm instructions Alarm Setting Detector panel setting Data Display 4digits LCD direct indication LCD Dimensions 47mmx28.5mm Detector Dimensions 175mmx170mmx130mm Installing Screw Hole Size ?8mm Quality Detector: 960g Working Temperature and Humidity -10°C~ 45°C; 20%RH ~ 90%RH Humiture Error Within 5% Shift Automatic shift GND Interference Current Prohibited External Magnetic Field

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ETCR
Country/Region of Manufacture	China
Model	ETCR2800C
