Eu Free!cnc Wantai 4axis Nema 34 Stepper Motor 2a 623/890oz-in&driver 80v 7.8a

US $485.00

Hamburg, Germany
Jun 9th

Open on mobile:
QR code

Hi,guys!Welcome to my shop! It's my honor to solve your any problem. Great News from Wantaimotor! Ship from Germany warehouse to European Union Customers! No taxes from customs, no damage, better service, please don't hesitate! his item includes: 4 PCS Nema 34 Stepper Motors 85BYGH450D-007 94mm 2.0A Holding Torque:4.4N.m(623oz-in)with unipolar; 6.3N.m(890oz-in) with bipolar 4 pcs stepper motor driver DQ860MA 7.8A 80V 256microsteps 2 pcs power supply:350W 48V 1 PC Breakout Board & 1 Cable for free offering 1)stepper motor 2)stepper motor driver Introduction: DQ860MA is a type of two-phase hybrid stepping motor driver, the drive voltage of it is from 24VDC to 80VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 57mm to 110mm outside diameter and less than 7.8A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly almost without noise and vibration. Holding torque when DQ860MA runs under high speed, is also significantly higher than the other two-phase driver, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, and computer embroider machine, packing machines and so on. Features: High performance, low price Average current control, 2-phase sinusoidal output current drive Supply voltage from 24VDC to 80VDC Opto-isolated signal I/O Overvoltage, under voltage, overcurrent, phase short circuit protection 14 channels subdivision and automatic idle-current reduction 8 channels output phase current setting Offline command input terminal Motor torque is related to speed, but not related to step/revolution High start speed High holding torque under high speed Electrical specification: Input voltage 24-80VDC Input current < 6A Output current 2.8A~7.8A Consumption Consumption:80W; Internal Insurance:10A Temperature Working Temperature -10~45°C; Stocking temperature -40°C~70°C Humidity No condensation, no water droplets gas Prohibition of combustible gases and conductive dust weight 500G 3) power supply Index Type S-350-5 S-350-7.5 S-350-12 S-350-15 S-350-24 S-350-27 S-350-48 DC Voltage 5V 7.5V 12V 15V 24V 27V 48V Voltage Tolerance ± 2% ± 2% ± 1% ± 1% ± 1% ± 1% ± 1% Rated Current 50A 40A 29A 23A 14.6A 13A 7.3A Current Range 0-50A 0-40A 0-29A 0-23A 0-14.6A 0-13A 0-7.3A Ripple&Noise(Max.) 150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p 240mVp-p Line Regulation ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5% Load Regulation ± 1% ± 1% ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5% Rated Power 250W 300W 348W 348W 350.4W 351W 350.4W Rated Power 74% 79% 74% 78% 83% 83% 84% Voltage Adjust Range 4.5-5.6V 6-9V 10-13.2V 13.5-18V 20-26.4V 26-32V 41-56V Voltage Range 90~132VAC/180-264VAC 47~63Hz;255~370VDC AC Current 4.5A/115V 2.5A/230V Inrush Current(Max.) 25A/115V 50A/230V Leakage Current <3.5mA/240VAC Overload Protection 105-145% TYPE:OUTPUT CUTOUT AC Restart Over-voltage Protection 115%-135% Over-temperature Protection RTH3>=50°C FAN ON=80°C OUTPUT CUTOUT(5-15V) RTH3>=60°C FAN ON=85°C OUTPUT CUTOUT(24-48V) Temp.Coefficient ± 0.03%/°C(0~50°C) Setup.Rise,Hold Time 200ms,100ms,20ms Vibration 10~500Hz,2G 10min,/11cycle,60min,each axes Withstand Voltage I/P-O/P:3KVACI/P-FG:1.5KVACI/P-FG:0.5KVAC Isolated Resistor I/P-O/P,I/P-FG,I/P-FG:500VDC/100M? Working Temp.Humidity -10°C~+50°C,20%~90RH Storage Temp.Humidity -20°C~+85°C,10%~95%RH Dimension 215?A115?A50mm Weight 0.9kg Safety Standards UL1950 4) breakout board Description Built in DB25 male connector. DB25 output pin:P1,P2,P3,P4,P5,P6,P7,P8,P9,P14,P16,P17 DB25 input pin:P10,P11,P12,P13,P15. DB25 GND pin:P18-P25. Power supply:+5VDC Built in C-class optical-coupler. High quality with surface-mount Tech. It can connection 6 drivers and control 6 motors in the same time. Built in DB25 male connector. DB25 output pin:P1,P2,P3,P4,P5,P6,P7,P8,P9,P14,P16,P17 DB25 input pin:P10,P11,P12,P13,P15. DB25 GND pin:P18-P25. Power voltage is 5VDC and support with MACH3 ect.software Built in optical-coupler. You can set these pins according to software as follows: Output pins:P1,P2,P3,P4,P5,P6,P7,P8,P9,P14,P16,P17 P2-X axis Pulse,P3-X axis Direction; P4-Y axis Pulse,P5-Y axis Direction; P6-Z axis Pulse,P7-Z axis Direction; P8-A axis Pulse,P9-A axis Direction; P14-B axis Pulse,P1-B axis Direction; P16-C axis Pulse,P17-C axis Direction; Input pins:P10,P11,P12,P13,P15 Set them for Emergency Stop and X Y Z Limit switch Shipping details: 1.Please confirm your Address carefully before you make the order. 2.We will ship the goods 3 days later after we receive your order and they will arrive the destination(most of the country) within 5-30 days. 3.Please contact us if you don’t receive the goods in 45 days.We will check the package and the reason within 3 day. Payment: 1.we accept paypal,credit card and bank transfer. 2. Payment must be made within 5 days of the auction end time. 3.We are not responsible for any custom duty and import tax. Returns: 1.If the products are damaged,please provide photos for us,we need them. 2.If you are not satisfied with the goods,please tell us the reasons,they are important . 3.Buyers are responsible for delivery cost. 4.Once receiving goods,we will refund you immediately. Feedback: 1.We rely on our reputation,so ,your feedback is extremely important for us.Please leave good feedback if you are satisfied with our goods and service. 2.Please give us the opportunity to solve any problem,we will do our best to solve the issues before leaving any negative feedback or opening any dispute on the site. Application: Our products are mainly used in Robotization,Spinning Automatization,Printing,Packing Medica Machine,Make-up Equipment,Communication,Household Appliance,Water Pump,Milling Machine,Engraver Machine,CNC Routers..ect automatic equipment of various trades. Contact me: Att:Zoe E-mail:zoe@wantmotor.com MSN:zongxueqin1992@outlook.com Skype:zongxueqin1992 Tel:0086-519-85138377 Mobile:0086-13813587529 All email will be answered within 24 hours.If you don’t receive our reply,please kindly re-send again and we will reply you asap.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	WANTAI
MPN	www.wantmotor.com
Model	85BYGH450D-007
Country/Region of Manufacture	China
