Fair-rite 5961001001 Ferrite Core, F-114-61,toroid, 61 Mat'l (15 Pieces A Lot)

US $770

  • Orange, California, United States
  • Jun 12th
FAIR-RITE 5961001001 FERRITE CORE, TOROID, 61 material, Permeability 125 You are buying a lot of (15 pieces).  Part Number: 5961001001 / F-114-61 FERRITE CORE, TOROID Toroid Core Size: OD = 29 mm (1.142 inch) x ID = 19 mm (0.748 inch) x HT = 7.5mm (0.295 inch)   Le = Effective Magnetic Path Length: 17.3 cm  Ae = Effective Cross Section Area: 0.37 cm2  Ve = Volume : 2.70 cm3 Al = Inductance Factor Al: 80 nH  RoHS Compliant Application / Uses :  Power Input filters, Ground fault interrupters, Common mode filters, Pulse transformers, Matching transformers. The material 61 types is particularly suitable for building transmission line transformer design by Dr. Jerry Sevick, W2FMI.
