MAGNETICS FERRITE CORE, ZJ-42507-TC, F-100-JC TOROID, J mat'l (15 pieces a lot), US $1900 – Picture 0
MAGNETICS FERRITE CORE, ZJ-42507-TC, F-100-JC TOROID, J mat'l (15 pieces a lot), US $1900 – Picture 0

Magnetics Ferrite Core, Zj-42507-tc, F-100-jc Toroid, J Mat'l (15 Pieces A Lot)

US $1900

  • Orange, California, United States
  • Jun 12th
Open on mobile:
QR code
MAGNETICS INC ZJ-42507-TC  FERRITE CORE, COATED TOROID, J MATERIAL, Permeability 5000 You are buying a lot of (15 pieces).  Part Number: ZJ-42507-TC / F-100-JC Manufactured by Magnetics Inc, Pennslyvania, USA Core Type: Toroids Toroid Core Size: OD = 25.4 mm (1.00 inch) x ID = 15.5 mm (0.610 inch) x HT=7.92 mm (0.312 inch)   Material Grade: J Permeability of 5000  Saturation Flux density 4300 at 15 oersted, 25 deg C Le = Effective Magnetic Path Length: 6.17 cm  Ae = Effective Cross Scetion Area:0.374 cm2  Al = Inductance Factor : 3913 nH  RoHS Compliant Application / Uses :  J material with permeability of 5000 is the most widely used ferrites core for common mode chokes. It is also used as EMI/RFI filters for amateur radio bands ( 3 Mhz to 30 Mhz) by wrapping the cables around the cores. As Common mode chokes and filters, the effective range is filtering out noise from 1 Mhz to 100 Mhz.
