Fda Ce 30w Fiber Laser Marking Metal Engraving Engraver Ratory Axis + Gift

US $4,137.25

Jamaica, New York, United States
Jul 23rd

Open on mobile:
QR code

30W Split Fiber Laser Marking and Engraving Machine, Rotary Axis Include, for Metal and Non-metal Material Marking CA & NY States warehouses Raycus Laser Licensed Ezcad2 software BJJCZ Board Rotary Axis Include Lens Optional110mm, 150mm, 175mm, 200mm, 300mm 3 Years Warranty! 24h Technical Support by Email or Video Calling! Shipping Out Within 24 Hours, Fast Door to Door Delivery! No extra fee, no custom handling troubles 2 red dot focus Function The machine equip with software. Fiber Laser Marking Machine mainly consists of four parts: fiber laser, galvanometer scanning system, computer control system and the worktable. Name Origin (brand) Remarks Optical maser Raycus/MAX Long service life, high reliability, fine beam quality Galvo mirror Galvo-tech (digital) Fine marking, more quick and high reliability F- lens Wavelength High quality optical device Board bjjcz 2.12.0 version Marking software Special marking Software (Ezcad2 software) Powerful, simple and convenient operation, Auto-cad, CorelDraw, AI8.0, Photoshop software compatible form Control cabinet China Optical fiber special cabinet, all the mold production, high seal Feature: 1. Optical Fiber Laser, environment friendly, easy maintenance. 2. Life of the laser can be up to 100000 hours. 3. Small volume and weight, less than 35KGS. 4. Easy operation software, compatible with PHOTOSHOP, CORELDRAW, AUTOCAD 5. Runs without consumable spare parts, no need maintenance, great for continuous working. 6. Computer System Requirements: Win7, Win8, Win10 Rotary Plus is more suitable for rings, jewelry and other small diameter products. Specification: Specification Form Model LMM-JL-30W-S-US Fiber Laser Source RAYCUS ( Maxphotonics/IPG laser optional) Output Power 30W Laser wavelength 1064nm Modulation frequency range 40-60kHz Speed 0-8000mm/s Precision 0.001mm Minimum line width 0.01mm Minimum height of characters 0.05mm Cooling way Air cooling Marking range 110mm x 110mm/175mm x 175mm (150mm x 150mm / 200mm x 200mm / 300mm x 300mm optional) Laser power supply 0.5KW,110V/60HZ Software Auto-cad, CorelDraw, AI8.0, Photoshop software compatible Rotary device Yes Weight 35KGS Computer System Requirements Win7,Win8,Win10 Packing List: Machine Dimension 70cm x 20cm x 50cm (28in x 8in x 19.7in) Machine Weight 35kg (77lbs) Packing Size 81.5 x 46 x 74cm (32 x 10.2 x 29.1in) Packing Weight 61kg (134.48lbs) Package Wooden box Accessories list with marker Power line, USB wire, software and manual CD Details: 1.The galvanometer scanning system is made of optical scanner and servo control of two parts, the whole system adopts new technology, new material, new design and manufacturing. 2.The smallest volume, suitable for harsh environment, friendly interface, easy operation. 3.Adopts the high quality, high energy, high stability fiber laser source, prime precision optical galvanometer assembly and the industry’s top software. 4.Compact, lightweight, simple interface, flexible and adjustable processing direction. 5.The master switch, red light switch and galvanometer switch, 6.High precision scale 7.Ratory axis is included, you can mark on regular cylinder or inside / outside ring. Application Industry: Jewellery, Keyboards of cell phone, Auto parts, Electronic components, Electronic appliance, Communication apparatus, sanitary wares, buckles, kitchenware, Sanitary equipment’s, Hardware tools, Knife, Glasses, Clock, Cooker, Stainless steel products etc. Application: Fiber Laser Machine Applied Materials Metal Non-metal Aluminum Makrolon Polycarbonate Stainless Steel Black / White ABS Copper Nylon Silicon Steel Polysulphone Yellow Chromate Aluminum Rynite PET Brass Santoprene Nickel Plated Brass / Gold / Kovar / Steel Sillicon Carbide Nickel Plated 1215 Mild Steel Glass Filled Teflon Hard Coat Anodized Aluminum White PEEK Machine Tool Steel Glass Filled PEEK Metal Plated Ceramics Silicon Wafers Magnesium Carbon Nanotube Molybdenum Colored Delrin Carbon Fiber / Carbon Nano tube GE Plastics Polycarbonate Resin 121-R Clear coat anodized aluminum Polybutylene Terephthalate Cobalt Chrome Steel Compacted Powder Iron / Iron Phosphate Coating 1. Aluminum Aluminum is one of the most commonly marked substrates, and we use it in many industries. Typically, with lighter marking intensity, aluminum will turn white. anodized aluminum looks good , but white marking is not ideal for bare and cast aluminum. More intense laser settings provide a dark grey or charcoal color. Each DLM fiber laser engraving machine is capable for aluminum marking. The ideal system for your application depends on your laser marking requirements. Ablation is the most common marking technique for anodized aluminum, but some people call for etching or engraving. 2. Brass and copper Brass and copper have high thermal conductivity and thermal transfer properties. So we use it for wiring, printed circuit boards and pressurized flow meters. Their thermal properties are ideal for laser marking systems for metal because the heat is quickly dissipated. This reduces the impact the laser can have on the structural integrity of the material. Every DLM fiber laser engraving machine is capable of marking on brass and copper and the ideal system for your application depends on your marking requirements. The best marking technique depends on the finish of the brass or copper. Smooth surfaces can offer a soft polished marking affect, but also can do annealed, etched, or engraved. Etching or engraving is best in order to provide readability by humans and machines. In some cases a dark anneal can work, but surface irregularities can cause reduced readability. 3. Tungsten and Carbide Tungsten and Carbide are two of the hardest metals on earth and are widely used in tooling and cutting applications. Another popular segment for these substrates is wedding bands for men. Tungsten and carbide are receptive laser marking metals and laser engraving metals. Each and every DLM Laser series is capable of marking on tungsten and carbide and the ideal system for your application depends on your marking requirements. For carbide, because of the darker color it naturally has, getting a contrasting mark is rather easy with even light laser intensity. A white color is most common when polishing or annealing carbide and the contrast is extremely good. 4. Chrome Chrome plating provides a stylish and sophisticated finish, and usually requires minimal laser intensity to remove or get through the plating. we need take ensure the marking happens on the surface only, with no impact to the chrome plating. Packing List: Machine Dimension 70 x 20 x 50cm (27.9 x 7.9 x 19.7in) Machine Weight 35kg (77.16lb) Packing Size 110 x 36 x 70cm (43.3 x 14.2 x 27.6in) Packing Weight 61kg (134.48lb) Package Wooden box Accessories list with marker Power line, USB wire, software and manual CD Why buy from us? Buy from the expert! All of our product is direct from original manufacturer, who also supplies the brand name to domestic market but with much higher price. We are in the industry so we understand what is good for you and what is not. We offer this special purchase and pass this saving direct to our customer, We use what we are selling so we will have the best support than other sellers. Buy from an direct importer! As a direct importer, we buy direct from manufactures so we can guarantee you have the lowest price and top quality products! In addition, we have bulk price to save your cost even more. We work Harder. We get the lowest possible delivery fee for you. We dispatch goods as soon as possible for your urgent order. We have customer support to save your time. We understand what you need in your business. WE can give you professional advices, suggestions and ways to further reduce your productions cost in the long run. Please free to contact us if you need more information.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Split Fiber Laser Marking Engraving Machine
Speed	0-8000mm/s
Modified Item	No
Laser power supply	0.5KW, 110V / 60HZ
Custom Bundle	No
Software	Auto-cad, CorelDraw, AI8.0, Photoshop software com
Material	Metal
Graphic Format Supported	AI / BMP / DST / DWG / PLT
Precision	0.001mm
Fiber Laser Source	Raycus
Minimum line width	0.01mm
Output Power	30W
Engraving Method	Laser
Laser wavelength	1064nm
MPN	011600309530030953
Modulation frequency range	20-100kHz
Cooling way	Air cooling
Power	30W
Marking range	175mm x 175mm
Brand	CALCA
UPC	8011717224506
