Fluke 743b Documenting Process Calibrator / Meter/sourcemeter/voltmeter/dmm+

US $880

Chicago, Illinois, United States
Jun 9th

Open on mobile:
QR code

Up for sale is this Fluke 743B Document Process Calibrator. As you can see the meter turns on.....whatever is shown on the pictures is included. I do have Pressure Modules if you are interested, please send me a private message and I will include model #'s and pricing. The 743B does the work of several tools – sourcing, simulating and measuring pressure, temperature, and electrical signals in one rugged, hand-held device. For documentation, the 743B automates calibration procedures and captures your data. And, of course, it helps you meet rigorous standards like ISO 9000, FDA, EPA and OSHA regulations. The 743B has a PC interface that lets you download procedures, lists, and instructions created with software-or upload data for printing, archiving, and analysis. With its expanded memory, the 743B can hold a full week of calibrations and procedures. The 743B is easy to use with flexible test strategies. And like all Fluke tools, it's rugged, reliable and tough as nails. It's like having several powerful tools in one - so you can work faster than ever: Measure volts, mA, RTDs, thermocouples, frequency, and ohms to test sensors, transmitters and other instruments Source/simulate volts, mA, thermocouples , RTDs, frequency, ohms, and pressure to calibrate transmitters Power transmitters during test using loop supply with simultaneous mA measurement Measure/source pressure using any of 29 Fluke 700Pxx Pressure Modules Measure and source with one compact, rugged, reliable tool Create and run automated as-found/as-left procedures to satisfy quality programs or regulations. Record and document results Use many features like auto step, custom units, user entered values during test, one-point and two-point switch testing, square root DP flow testing, programmable measurement delay etc. Easy to use Three year warranty Bright white display. Read both sourced and measured parameters. Multi lingual interface Handling of fast pulsed RTD transmitters and PLCs, with pulses as short as 1msec. Standard delivered with DPC/Track Sample software. Compatible with many Asset Management software packages. DC Voltage Measurement Specifications: Range: Resolution: % of Reading + % of Full Scale: 1 Year: 2 Year: 110 mV 1 µV 0.025% + 0.015% 0.05% + 0.015% 1.1 V 10 µV 0.025% + 0.005% 0.05% + 0.005% 11 V 100 µV 0.025% + 0.005% 0.05% + 0.005% 110 V 1 mV 0.025% + 0.005% 0.1% + 0.005% 300 V 10 mV 0.025% + 0.005% 0.1% + 0.005% Temperature Coefficient: (0.001% of rdg. + 0.0015% f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C Input Impedance: 5 M? Common Mode Error: 0.008% f.s./(Common Mode Volt) Maximum Input Voltage: 300 V rms AC Voltage Measurement Specifications: Frequency Range: % of Reading + Number of Counts: 1 Year: 2 Year: 20 Hz to 40 Hz 2% + 10 2% + 10 40 Hz to 500 Hz 0.5% + 5 0.5% + 5 500 Hz to 1 kHz 2% + 10 2% + 10 1 kHz to 5 kHz 10% + 20 10% + 20 Ranges: 1.1000 V, 11.000 V, 110.00 V, 300.0 V rms Resolution: 11.000 counts in all ranges except 300 V; 3,000 counts on 300 V range. Input Impedance: 5 M? and < 100 pF Temperature Coefficient: 10% of specification/°C in the ranges -10 to 18°C and 28 to 50°C Input Coupling: AC Maximum Input Voltage: 300 V rms Maximum Input Voltage: 0.5 V above 1 kHz Note: Specifications apply for 10% to 100% of voltage range. DC Current Measurement: Range: Resolution: % of Reading + % of Full Scale: 1 Year: 2 Year: 30 mA 1 µA 0.01% + 0.015% 0.02% + 0.015% 110 mA 10 µA 0.01% + 0.015% 0.02% + 0.015% Temperature Coefficient: (0.001% of rdg. + 0.002% f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C Common Mode Error: 0.01% f.s./(Common Mode Voltage) Maximum Input Voltage: 30 V dc Resistance Measurement Specifications: Range: Resolution: % of Reading + ohms: 1 Year: 2 Year: 11 ? 0.001 ? 0.05% + 0.05 0.075% + 0.05 110 ? 0.01 ? 0.05% + 0.05 0.075% + 0.05 1.1 k? 0.1 ? 0.05% + 0.5 0.075% + 0.5 11 ?k 1 ? 0.1% + 10 0.1% + 10 Temperature Coefficient: (0.01% f.s. + 2 m?)/°C in teh ranges -10 to 18°C and 28 to 50°C Common Mode Error: 0.005% f.s./(Common Mode Voltage) Maximum Input Voltage: 30 V dc Continuity Testing: Tone: Resistance: Continuous tone < 25 ? May or may not get tone 25 to 400 ? No tone > 400 ? Frequency Measurement Specifications: Ranges: Accuracy: 1 Year: 2 Year: 1.00 Hz to 109.99 Hz 0.05 Hz 0.05 Hz 110.0 Hz to 1099.9 Hz 0.5 Hz 0.5 Hz 1.100 kHz to 10.999 kHz 0.005 kHz 0.005 kHz 11.00 kHz to 50.00 kHz 0.05 kHz 0.05 kHz Minimum Amplitude for Frequency Measurement (square wave): <1 kHz: 300 mV p-p 1 kHz to 30 kHz: 1.4 V p-p > 30 kHz: 2.8 V p-p Maximum Input: < 1 kHz: 300 V rms > 1 kHz: 30 V rms Input Impedance: 5 M? Notes: For frequency measurement less than 109.99 Hz, specifications apply for signals with a slew rate greater than 5 volt/millisecond. DC Voltage Output Specifications: Range: Resolution: % of Output + % of Full Scale: 1 Year: 2 Year: 110 mV 1 µV 0.01% + 0.005% 0.015% + 0.005% 1.1 V 10 µV 0.01% + 0.005% 0.015% + 0.005% 15 V 100 µV 0.01% + 0.005% 0.015% + 0.005% Temperature Coefficient: (0.001% of output + 0.001% of f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C Maximum Output Current: 10 mA Loading: (0.001% f.s. + 1 µV)/mA Common Mode Error: 0.008% f.s./(Common Mode Voltage) Maximum Input Voltage: 30 V dc DC Current Output: Range/Mode: Resolution: % of Output + % of Full Scale: 1 Year: 2 Year: 22 mA/Source mA 1 µA 0.01% + 0.015% 0.02% + 0.015% 22 mA/Simulate Transmitter (Current Sink) 1 µA 0.02% + 0.03% 0.02% + 0.03% Maximum Burden Voltage: 24 V Temperature Coefficient: (0.003% of output + 0.003% of f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C Common Mode Error: 0.008% f.s./(Common Mode Voltage) Maximum Input Voltage: 30 Vdc Notes: Specification applies for currents between 2 mA and 22 mA. For current below 2 mA, typical accuracy is 0.15% of full scale. Resistance Sourcing Specifications: Range: Resolution: % of Output + % of ohms: 1 Year: 2 Year: 11.000 1 m 0.01% + 0.02 0.02% + 0.02 110.00 10 m 0.01% + 0.04 0.02% + 0.04 1.1000 k 100 m 0.02% + 0.5 0.03% + 0.5 11.000 k 1 0.03% + 5 0.04% + 5 Temperature Coefficient: (0.01% of f.s.)/°C in the ranges -10 to 18°C and 28 to 50°C Maximum and Minimum Current through Source Resistance: 11 ? Range: 3 mA dc max, 0.1 mA dc min 110 ? Range: 3 mA dc max, 0.1 mA dc min 1.1 k? Range: 3 mA dc max, 0.01 mA dc min 11 k? Range: 1 mA dc max, 0.01 mA dc min Common Mode Error: 0.008%/f.s./(Common Mode Voltage) Maximum Input Voltage: 30 V dc Frequency Sourcing Specifications: Range: % of Output + % of ohms: 1 and 2 Year: 0.00 Hz 0.01 Hz 11.00 Hz to 109.99 Hz 0.1 Hz 110.0 Hz to 1099.9 Hz 0.1 Hz 1.100 kHz to 21.999 kHz 0.002 kHz 22.000 kHz to 50.000 kHz 0.005 kHz Waveform Choices: Zero-symmetric sine or positive square wave, 50% duty cycle. Amplitude: 0.1 to 10 V pk Amplitude Accuracy: 0 Hz to 1099 Hz: 3% of output + 0.5% f.s. 1.1 kHz to 10.9 kHz: 10% of output + 0.5% f.s. 11 kHz to 50 kHz: 30% of output + 0.5% f.s. Maximum Input Voltage: 30 V dc Temperature Thermocouples Specifications: Type: Range °C: Measures °C: Source °C: 1 Year: 2 Year: 1 Year: 2 Year: E: -250 to -200 1.3 2.0 0.6 0.9 -200 to -100 0.5 0.8 0.3 0.4 -200 to -100 0.5 0.8 0.3 0.4 600 to 1000 0.4 0.6 0.2 0.3 N: -200 to -100 1.0 1.5 0.6 0.9 -100 to 900 0.5 0.8 0.5 0.8 900 to 1300 0.6 0.9 0.3 0.4 J: -210 to -100 0.6 0.9 0.3 0.4 -100 to 800 0.3 0.4 0.2 0.3 800 to 1200 0.5 0.8 0.2 0.3 K: -200 to -100 0.7 1.0 0.4 0.6 -100 to 400 0.3 0.4 0.3 0.4 400 to 1200 0.5 0.8 0.3 0.4 1200 to 1372 0.7 1.0 0.3 0.4 T: -250 to -200 1.7 2.5 0.9 1.4 -200 to 0 0.6 0.9 0.4 0.6 0 to 400 0.3 0.4 0.3 0.4 B: 600 to 800 1.3 2.0 1.0 1.5 800 to 1000 1.0 1.5 0.8 1.2 1000 to 1820 0.9 1.3 0.8 1.2 R: -20 to 0 2.3 2.8 1.2 1.8 0 to 100 1.5 2.2 1.1 1.7 100 to 1767 1.0 1.5 0.9 1.4 S: -20 to 0 2.3 2.8 1.2 1.8 0 to 200 1.5 2.1 1.1 1.7 200 to 1400 0.9 1.4 0.9 1.4 1400 to 1767 1.1 1.7 1.0 1.5 C: 0 to 800 0.6 0.9 0.6 0.9 800 to 1200 0.8 1.2 0.7 1.0 1200 to 1800 1.1 1.6 0.9 1.4 1800 to 2316 2.0 3.0 1.3 2.0 L: -200 to -100 0.6 0.9 0.3 0.4 -100 to 800 0.3 0.4 0.2 0.3 800 to 900 0.5 0.8 0.2 0.3 U: -200 to 0 0.6 0.9 0.4 0.6 0 to 600 0.3 0.4 0.3 0.4 Resolution: 0.1°C Temperature Scale: ITS-90 or IPTS-68, selectable Compensation: ITS-90 per NIST Monograph 175 for B, R, S, E, J, J, B, T; IPTS-68 per IEC 584-1 for B, R, S, E, J, K, T; IPTS-68 per DIN 43710 for L, U. Temperature Coefficient: 0.05°C/°C in the range -10 to 18°C and 28 to 50°C Common Mode Error: 0.01°C/(Common Mode Voltage) Maximum Input Voltage: 30 V Notes: Sensor inaccuracies not included. Accuracy with external cold junction; for internal injunction add 0.2°C. Temperature, Resistance Temperature Detectors Specifications: Type (?): Range °C: Measure °C: Source °C: 1 Year: 2 Year: 1 Year: 2 Year: 100 ? Pt (3926): -200 to 0 0.3 0.4 0.1 0.2 0 to 630 0.5 0.8 0.2 0.4 100 ? Pt(385): -200 to 0 0.3 0.5 0.1 0.2 0 to 400 0.5 0.8 0.2 0.4 400 to 800 0.8 1.0 0.4 0.5 120 ? Ni(672): -200 to 260 0.3 0.4 0.1 0.2 200 ? Pt(385): -200 to 0 0.3 0.5 0.1 0.2 0 to 400 0.5 0.8 0.2 0.4 400 to 630 0.8 1.0 0.4 0.5 500 ? Pt(385): -200 to 0 0.3 0.5 0.1 0.2 0 to 400 0.5 0.8 0.2 0.4 400 to 630 0.8 1.0 0.4 0.5 1000 ? Pt(385): -200 to 0 0.3 0.5 0.1 0.2 0 to 400 0.5 0.8 0.2 0.4 400 to 360 0.8 1.0 0.4 0.5 10 ? Cu(427): -100 to 0 2 2 1 1 0 to 260 2 2 1 1 100 ? Pt(3916): -200 to -190 0.3 0.4 0.3 0.4 -190 to 0 0.3 0.4 0.1 0.2 800 to 1200 0.5 0.8 0.2 0.4 Resolution: 0.1°C Temperature Coefficient: 0.02°C/°C in the ranges -10 to 18°C and 28 to 50°C Maximum Input Voltage: 30 V Maximum Input Current for RTD Source: 10 ? RTDs: 8 mA dc 100 ? - 120? RTDs: 3 mA dc 200 &Omega - 1000 ? RTDs: 1 mA dc Notes: Sensor inaccuracies not included. For two and three-wire RTD measurements, add 0.4°C to the specifications. General Specifications: Display: 240 x 200 pixel graphic LCD, 70 x 58 mm. Power: Internal battery pack: NiCd, 7.2 V, 1700 mAh Memory Backup: Lithium battery, 5 years typical lifetime. Dimensions: 130 x 236 x 61 mm (5.1 x 9.3 x 2.4 in). Weight: 1.4 kg (3 lb. 1 oz.) Altitude: Up to 2800 meters (9186 ft) above mean sea level. Operating Temperature: -10 to 50°C (typically to -20°C, except for frequency measure and ac voltage measure) Storage Temperature: -20 to 60°C Humidity: Avoid prolonged use outside the safe operating boundaries shown in the graph in the manual. Water/Dust Protection: Designed to meet IEC529 IP52 (normal operating vacuum used for dust test.) Safety: Designed in accordance with ANSI/ISA-S82 .01-1994, UL3111, CAN/CSA C22.2 No. 1010.1-92, and EN610-10:1993.
