Wl Hvt-2601 Tft-lcd Cctv Tester With Ip Address Scan And Cable Tester

US $260

HONGKONG, China
Jun 9th

Open on mobile:
QR code

Overview The new CCTV tester is developed for the On-Site installation and maintenance of IP camera,analog camera and network device, with Video display, PTZ control, DC12v output power, Audio test, Color bar generator, RS 485 Data searching and Cable testing, which are the same to the previous models. The new developed functions include POE power supply testing, PING testing, IP address scan, Video snapshot, Video record, Image magnification, Port flicker, LED lamp etc. The new tester also has built in TDR cable testing, which is specialized designed for BNC cable testing in the security monitoring system. This function can accurately measure BNC cable and network cable’s break point and short-circuit location. The new tester designed with easy operation and portability makes it simple for a cctv technician or installer to install and maintain CCTV systems, improving work efficiency by reducing time in the field. Applications —Find out the other end of the cable in security maintenance and network engineering —CCTV system installation and maintenance —Dome camera and All in one camera testing —The CCTV transmitting channel testing —PTZ controller Features —3.5 inch full-view TFT-LCD, 480(RGB)x320 NEW —low consumption, work for 11 hours —OSD menu, English, Chinese and other languages optional —LCD screen brightness/contrast/color Saturation adjustable —Automatically identify and adapt the video mode of NTSC and PAL —Enhanced colorbar generator,by receiving the video color bar to test the video channel whether transmit normally NEW —Moveable Micro SD NEW —LED Lamp, easy to operate at night NEW —User-defined shortcut keys(F1 and F2) NEW —10x zoom,video image can be magnified to view the details, easy to use NEW —Snapshot and save the current image as JPG file in the SD card NEW —PING testing,test IP camera or other network devices’ ethernet port whether work normally, and the IP address whether is right NEW —IP address scan, quickly search the IP address for the connected IP camera and other network devices NEW —POE voltage measurement, test the PoE switch’s voltage to IP cameras, wireless AP device and other PD devices NEW —Device Port flicker, easy to find the connected PoE switch port by sending special signals, the connected PoE port will flicker at special frequency. NEW —Link monitor; check the setting IP address whether occupied .NEW —TDR break point and short – circuit measurement( BNC cable, network cable etc) NEW —PTZ address scan, search up the ID of PTZ camera. —Network cable and Telephone cable testing, display the sequence of connection and the No of the LAN cable —Multi-protocol. Supports more than thirty PTZ protocols. Such as PELCO-P, PELCO-D, SAMSUNG —Support RS232/RS485/RS422,rate 600 ~ 115200bps adjustable —Lithium Ion Polymer Battery.The device employs advanced power control and protection circuit —Display the data and image in on the screen at the same time. —Easy for use that the train is almost unnecessary Specifications Model HVT CCTV TESTER HVT-2601 ( 6th generation) Video Test Signal mode NTSC/PAL (Auto adapt) Display 3.5 inch digital TFT-LCD ,480(RGB)x 320 resolution LCD adjustment Brightness, Contrast, Saturation adjustable Video IN/OUT 1 channel BNC Input & 1 channel Output Video Output Mode 1.0 Vp-p Video Level test Level test Video signals measured in IRE or mV PTZ controller Communication Support RS232 and RS485 PTZ Protocol Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc. Baud Rate 600,1200,2400,4800,9600,19200,57600,115200bps Video Signal Generation Color bar generator Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color ) UTP CABLE TEST UTP cable test Test UTP cable connection status and display in the screen. Read the number of the test box. DC12V 1A power output DC12V power output Output DC12V1A power for camera Audio input test Audio input test test the pickup and other audio equipments on the front-end RS485 data analysis Data Monitor Captures and analyzes the command data from controlling device 10 x zoom of image Image 10x zoom 10x zoom image display and video out Photograph,Video record, Record playback Photograph snapshot and save the current image as JPG file Video record Video record and storage the file Record playback To view the storage file in the SD card Port flicker Port flicker Find the connected POE port quickly. IP scan, Link monitor, PING test IP scan Find out the connected IP camera or the other network equipment IP address quickly. Link Monitor Link monitor Check the IP address whether is occupied PING Testing PING testing Test IP camera or Ethernet port of the other network equipment whether work normally, and check the IP address POE tester POE tester Display the power supply voltage and cable connection states TDR Tester TDR Tester breakpoint and short circuit measurement(BNC cable, telephone cable) POWER Power Adapter DC 5V(1.5A) Battery Built-in 3.7V Lithium polymer battery,3000mAh Rechargeable After charging 3-4 hour, working time lasts 11 hours Low Consumption Energy saving technology, the battery icon real-time display Parameter Operation setting English/Chinese and other languages OSD menu Auto off 5-60 (mins) Keytone On/Off General Working Temperature -10°C---+50°C Working Humidity 30%-90% Dimension/ Weight 194mm x 112mm x 48mm / 540g
