Frm01 1 Single-channel Multifunction Relay Control Module E

US $8.66

Shenzhen, China
Jun 9th

Open on mobile:
QR code

FRM01 1 Single-Channel Multifunction Relay Control Module Description: FRM01 1 Single-Channel Multifunction Relay Control Module The FRM01 multifunction relay module, designed for the customers of a variety different needs , use MCU as the main control unit, have 9 functions according to user's need, customize and add other specific functions.and using of high-quality power relayi 1/4 ?high-withstand voltage transistori 1/4 ?red& blue signal lightsi 1/4 ?double-sided PCB boardi 1/4 ?layout considerations accurate and stable performance,widely used in various types of power control occasions. Features: The user can select one of the following nine functions. 1.Timing pull, after power-on, the relay delay period of time, delay time 1-99999 seconds adjustable; 2. Timing off, after power-on, the relay immediately pull ,delay for a period of time relay off ,delay time adjustable 1-99999 seconds; 3.Cycle timing mode A: after power-on, relay does not pull, upon the delay time T1 arrival the relay pull; after pull time T2 arrival the relay off, and then repeat the above state. 4.Cycle timing mode B: after power-on, the relay immediately pull, upon the delay time T1 arrivalthe relay off; after off time T2 arrival the relay pull, and then repeat the above state. 5.Latching relay (KIP) mode A: give the relay CH1 interface a pulse signal (rising edge), the relay pull, again give a pulse signal (rising edge)the relay off; 6.Latching relay (KIP) Mode B: give the relay CH1 interface a pulse signal (falling edge), the relay pull, again give a pulse signal (falling edge),the relay off. 7.Trigger relay mode A: give the relay CH1 interface a high level signal,the relay pull, when the high level signal disappear,the relay off . 8.Trigger relay mode B: give the relay CH1 interface a low-level signal or no signal,the relay pull,when the signal goes high, the relay off. 9.The user customization function: customizable function according to user request. Relay Module Interface The module control terminal: 3-wire interface, all interfaces have terminal blocks, very convenient. 1. DC+ : The positive electrode of the DC power (there is 5V, 12V and 24V modules to choose from) 2. DC- : The negative electrode of the DC power 3. CH1: Reserved Enter detection interface The relay module outputs: 3-wire interface, all interfaces have terminal blocks, very convenient. 1. NO1: the relay normally open contacts; 2. COM1: the Relay common contact; 3. NC1: the relay normally closed contacts. Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail(( no tracking number for items under $65), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.

Condition:	New: A brand-new, unused, unopened, undamaged item (including handmade items). See the seller's listing for full details. ...	Brand	Unbranded/Generic
UPC	Does not apply
