Gravity Conveyor 12" X 5' With 1.4" Rollers On 6" Centers

US $3892

Roseville, Michigan, United States
Nov 16th

Open on mobile:
QR code

HOTLINE: 586-771-1881 Gravity Conveyor 12" x 5' with 1.4" rollers on 6" centers Gravity Conveyor 12" x 5' with 1.4" rollers on 6" centers Gravity Conveyor Section A gravity conveyor section includes the conveyor frame and rollers. Gravity conveyors are one of the most cost effective and versatile product lines available. These conveyors are excellent for both permanent and temporary conveyor lines often found in warehouses, shipping departments and assembly areas. Gravity curves and spur options can add to the versatility of straight conveyors. Gravity roller conveyor can support heavier loads the skatewheel type conveyors. Ultimation gravity conveyors are available in lengths of 5′ and 10′ and widths of 12″, 15″ 18″, 24″, 30″, 36″ and wider. Roller centers are 1-1/2″, 3″, 4-1/2″ or 6″ between rollers. Frames are steel or aluminum. Roller diameters are 1-3/8″, 1.9″, 2.5″ (heavy duty) or 3.5″ (extreme duty). Note that for shipping to residential addresses, loads over 8′ long require special shipping arrangements. Features and dimensions of this particular gravity conveyor Model # RS14G12-6-5: 12″ Overall width (from outside of frame to outside of frame) 10″ between frames (i.e the widest product than can move along the conveyor) 5′ Overall length Galvanized 1-3/8″ diameter steel rollers Roller centers of 6″ between rollers Steel frame 2/12″ deep x 1″ flange x 12 ga. powder coated steel Paint color: Ultimation blue (other colors available with longer lead time) Couplings: Bolts one end; hooks on opposite end Total weight of this conveyor: 29 pounds Ships 5-6 business days after receipt of order Compatible with Hytrol SSR-12-6 series Leg supports are sold separately Load ratings of this conveyor Maximum load per roller: 50 pounds Maximum load per foot (without additional center supports): 260 pounds How to choose and configure the right gravity conveyor: Choose the gravity conveyor width you need based on the product dimensions. Allow 1″ each side. consider wider widths or fixed or adjustable side guides (optional) if the product may move sideways on the conveyor as it moves Decide on the length you need. Lengths of 5′, 10′ and curves can easily be joined together to achieve the layout required. Check the load rating table which shows the load capacity of each roller Decide on support centers. Support must be provide either at 5′ or 10′ intervals for all loads. Review the tables showing maximum “live” (moving) loads per foot that the conveyor frame is suitable for – remember to count the maximum number of products on the conveyor at once Make sure the product will move smoothly along the rollers and not get stuck between rollers. Choose the roller center distance (1-1/2″, 3″, 4-1/2″ or 6″ between rollers) so that the product is always gliding on at least 3 rollers at the same time (more if the product is uneven on the lower surface) See the “Downloads” tab on this page for a full catalog and more information Our staff are happy to assist you in analyzing the gravity conveyor you need Optional equipment (not included): Stationary floor support legs Portable tripod supports Portable T-stand carriages Butt couplings (in place of standard hooks and bolts, these brackets allow a more permanent connection with adjacent conveyor) Guide rails – Adjustable channel guide rails, fixed angle and channel guide rails See the “Downloads” tab on this page for catalogs and more information Note: Some product images show other models and/or optional additional equipment such as leg supports which are sold separately. Check specifications of this model before ordering Shipping Shipping cost: Configured by customer Delivery time: Most items ship within 48 hours of ordering Payment We accept the following payment methods: PayPal Please contact us if you have any questions. Customer Assistance Please call us on 586-771-1881 with any questions.
