Gsm/gprs/gnss/bluetooth Hat For Raspberry Pi

US $33.59

Swanton, Vermont, United States
Jul 18th

Open on mobile:
QR code

Description Raspberry Pi connectivity, compatible with Raspberry Pi 2B/3B/Zero/Zero W Supports SMS, phone call, GPRS, DTMF, HTTP, FTP, MMS, email, etc. Support GPS, COMPASS, Glonass, LBS base station positioning, omni-positioning Bluetooth 3.0, supports data transferring through Bluetooth Onboard USB TO UART converter CP2102 for UART debugging This is GSM/GPRS/GNSS/Bluetooth HAT for Raspberry Pi very handy, low power Raspberry Pi HAT which features multi communication functionalities: GSM, GPRS, GNSS and Bluetooth.It allows your Pi to easily make a telephone call, send messages, connect to wireless Internet, global position, transfer data via Bluetooth, and so on. Specifications 6x LEDs for indicating the module working status SIM card slot for 1.8V/3V SIM card RTC with backup battery holder Baudrate auto detection (1200bps ~115200bps) Control via AT commands (3GPP TS 27.007, 27.005, and SIMCOM enhanced AT Commands) Supports SIM application toolkit: GSM 11.14 Release 99 Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32) GSM/GPRS Band GSM 850/EGSM 900/DCS 1800/PCS 1900 MHz Quad-band auto search Compliant to GSM phase 2/2+ Emitting power Class 4 (2W @ GSM 850/EGSM 900 MHz) Class 1 (1W @ DCS 1800/PCS 1900 MHz) GPRS connectivity GPRS multi-slot class 12 (default) GPRS multi-slot class 1~12 (configurable) GPRS data feature Downlink speed: max 85.6kbps Uplink speed: max 85.6kbps Coding schemes: CS-1\CS-2\CS-3\CS-4 Supports PAP (Password Authentication Protocol) for PPP connection Supports PBCCH Supports USSD SMS Supports: MT/MO/CB/Text/PDU mode SMS storage: SIM card Audio Voice encode/decode mode: Half Rate\Full Rate\Enhanced Full Rate\Adaptive muti rate Supports echo cancellation Supports noise reduction GNSS Receiver type 33 tracking channels 99 acquisition channels GPS L1 C/A code Sensitivity Tracking: -165 dBm Cold starts : -148 dBm Time-To-First-Fix Cold starts : 28s (typ.) Hot starts : < 1s Warm starts: 26s Accuracy Horizontal position : <2.5m CEP Bluetooth Integrates AT commands Compliant to Bluetooth specification3.0 + EDR Supports SPP, OPP, HFP/HSP, etc. Misc Operating voltage: 5V Operating temperature: -40°C ~ 85°C Storage temperature: -45°C ~ 90°C What's Included 1 x GSM/GPRS/GNSS HAT 1 x GSM Antenna 1 x GPS External Antenna (B) 1 x Bluetooth Antenna 1 x USB type A plug to micro plug cable 1 x RPi screws pack (2pcs) Dimensions 30.2mm x 65mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Type	Waveshare
MPN	13460
UPC	Does not apply
