Hammond Sp100sr Control Transformer Ht5243 - Control Transformer 208x416v Pri 12

US $1100

Springtown, Texas, United States
May 28th

Open on mobile:
QR code

• Dimension: 2.990 Inch Length x 3.540 Inch Width x 2.850 Inch Height • Vacuum impregnated with polyester resin and oven cured • Coil face termination over 3000 VA or 30 Amp • Bolt-on mounting brackets • All terminal blocks utilize a combination slot/phillips #6 screw with a SEMS washer (suitable for 18 AWG to 14 AWG for solid wire and 18 AWG to 12 AWG for stranded wire), coil face terminations utilize a 1/4-20 UNC X 0.50 Inch combination slot/phillips screw and a spring lock washer • Primary and secondary winding • Not electrostatically shielded • 3.23 Inch height with finger guard Hammond 1-Phase Control transformer operates at 100 VA with the primary voltage of 208 x 416 Volts and secondary voltage of 12 x 24 Volts. It is ideal for general-purpose, industrial and light duty loads. Transformer offers an efficient and economical solution. It measures 2.990 Inch x 3.540 Inch x 2.850 Inch. Transformer has cooper winding with high dielectric strength insulation and offers screw terminals connection. It operates at frequency rating of 50/60 Hz and has rising temperature rating of 80 Deg C. Reverse connectable transformer is suited for HVAC applications, signal and alarm systems, motor control circuits, lighting and circuit isolation. It comes with open molded enclosure and offers panel mounting. Transformer has bolted core construction and offers air/dry cooling. It is UL listed and CSA certified. Product Specifications Amperage Rating 8.33/4.17 Amp Application Designed for Applications Where High Inrush or Machine Tool Duty are Not Necessary, the Hps Spartan Industrial Open-Style Control Transformer of fers an Efficient and Economical Solution, for HVAC Applications, Signal and Alarm Systems, Motor Control Circuits, Lighting and Circuit Isolation Catalog Description Industrial Open-Style Core & Coil Control Transformers Catalog Number SP100SR Connection Screw Terminal Country of Origin USA Depth 3.54 Enclosure Open coil Frequency Rating 50/60 Hz GTIN 00803423099398 Height 2.850 Inch Invoice Description English 100 VA 208X416 12X24 Item Control Transformer Length 2.990 Inch Mfr/Vendor Hammond Mounting 0.220 x 0.440 Inch Slot/Base/Panel Phase 1 Power Rating 100 VA Primary Voltage 208 x 416 Volt Secondary Voltage 12/24 Volt ShortDescriptionStripped Hammond-SP100SR-Control-Transformer Standard CSA/UL/CE Standards UL Listed, CE Certified, NEMA (ST-1), RoHS Compliant and CSA Certified Temperature Rating 80 deg C Rise, 130 deg C Insulation System UPC 803423099398 Width 3.540 Inch Winding CU Winding Material Copper description HMND SP100SR 100 VA 208X416 12X24 feature#1 Dimension: 2.990 Inch Length x 3.540 Inch Width x 2.850 Inch Height feature#2 Vacuum impregnated with polyester resin and oven cured feature#3 Coil face termination over 3000 VA or 30 Amp feature#4 Bolt-on mounting brackets feature#5 All terminal blocks utilize a combination slot/phillips #6 screw with a SEMS washer (suitable for 18 AWG to 14 AWG for solid wire and 18 AWG to 12 AWG for stranded wire), coil face terminations utilize a 1/4-20 UNC X 0.50 Inch combination slot/phillips screw and a spring lock washer feature#6 Primary and secondary winding feature#7 Not electrostatically shielded feature#8 3.23 Inch height with finger guard kVA Rating 100 Hoffman A24P24 Panel; Steel, White, (4) Hole Mount, For NEMA $86.11 Reviews Write a Review Q&A
