Hantek 1008b 8ch Usb Auto Scope/daq/8ch Programmable&oscilloscope Generator Gbw

US $1700

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

Search HOME DESCRIPTION PAYMENT SHIPPING Hantek 1008B 8CH USB Auto Scope/DAQ/8CH Programmable&Oscilloscope Generator GBW Product Description Feature: Oscilloscope 8 channels oscilloscope, 2.4MSa/s real time sampling rate 10mV/div to 5V/div input sensitivity, 8 gears adjustable 12 bits vertical resolution, spectrum analysis function Programmable Generator 8 channels programmable generator Others USB 2.0 interface plug and play, and no need extra power supply; More than 20 types of automatic testing function, a similar interface with benchtop oscilloscope, easy to use; Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7 Specifications: Brand New & High Quality Model Hantek 1008B Oscilloscope Mode Vertical Analog Channel 8 Input Impedance Resistance: 1MΩ Input Sensitivity 10mV/div to 5V/div Input Coupling DC Resolution 12 bits Horizontal Memory Depth 4K Max. Input 400V (DC+AC Peak) Real-Time Sampling Rate 2.4MSa/s Time Base Range 1ns/div to 20000s/div(1-2-5 sequences) Time Base Precision ±50ppm Trigger Source CH1, CH2,CH3,CH4, CH5, CH6,CH7,CH8 Mode Edge X-Y Mode X-Axis Input CH1 Y-Axis Input CH2 Cursors and Measurement Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Cursors Measurement Horizontal ,Vertical, Track, Auto Measure Modes Waveform Signal Process +,- , x,÷, FFT, Invert Voltage Range 10mV to 5V/div @ x 1 probe 100mV to 50V/div @ x 10 probe 10V to 5000V/div @ x 1000 probe 100V to 50000V/div @ x 10000 probe 200mV to 100V/div @ 20:1 Current Range 100mA to 50.0A/div @ CC65(20A) 1000mA to 500.0A/div @ CC65(65A) 1A to 100.0A/div @ CC650(60A) 10A to 1000.0A/div @ CC650(650A) 1A to 200.0A/div @CC1100(100A) 10A to 2000.0A/div @CC1100(1100A) Cursor Time/frequency difference, voltage difference FFT Rectangular, Hanning, Hamming, Blackman Window Math Addition, subtraction, multiplication, division Programmable Generator Channel 8 Output Level LVTTL Frequency Range 0-250kHz Interface USB 2.0 Power No need extra power supply Measurement Size 185 x 150 x 27 (mm) Weight 0.35kg Package includes: 1 x Hantek 1008B 8CH USB Auto Scope/DAQ/8CH Programmable & Oscilloscope Generator PAYMENT We accept PayPal only. SHIPPING Your purchase will be shipped via economy airmail, and your patience will be very much appreciated. We also offer express shipping, which normally takes 4-7 working days to reach you. You should expect to pay any amount, if there is any, charged by the government in your respective country; this includes (and is not limited to) duties & taxes.
