Hantek 3.5 Inch Hdg1012a Arbitrary Signal Waveform Generator 40mhz~10mhz

US $338.00

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

HANTEK 3.5 inch HDG1012A Arbitrary Signal Waveform Generator 40mHz~10MHz Feature: Direct Digital Synthesis(DDS) technology, 2 independent output channels; 3.5-inch TFT display, English/Chinese menu; Minimum stable output waveform: 1mV/(50Ω); Frequency sweep, amplitude sweep, burst and A B add functions; Over voltage, over current, output short-circuit and reverse voltage protections Specification: Model HDG1022A HDG1012A Frequency range(sine) 40uHz~20MHz 40mHz~10MHz Output Characteristics of Channel A Waveform Characteristics Waveform type sine, square, pulse, DC Sine, Square, Triangle, Ramp, Pulse etc. Waveform length 4 ~ 16000 points 1024 points Sample rate 180MSa/s 100MSa/s Waveform amplitude resolution 10bits 8bits Sinusoidal harmonic rejection ≥50dBc (≤1MHz), ≥ 40dBc (1MHz ~ 20MHz), ≥30dBc (20MHz ~ 40MHz) ≥40dBc (<1MHz), ≥35dBc (1MHz~20MHz) Sine wave total distortion ≤0.5 % (20Hz ~ 200kHz) ≤1% (20Hz~200kHz) Pulse and square rise/fall time ≤20ns ≤35ns Pulse and square overshoot ≤5% ≤10% Square wave duty cycle 50% 1%~99% Pulse wave duty cycle 0.1%~ 99.9% -- Frequency Characteristics Frequency range sine:40μHz ~ 2kHz, resolution: 40μHz; 2kHz ~ the Max.frequency, resolution: 40 mHz; square: 40μHz~20mHz; pluse:40μHz~10mHz sine: 40mHz~Max.frequency (MHz); square: 40mHz~5MHz; other waveforms: 40mHz~1MHz; Frequency resolution -- 40mHz Frequency accuracy ±(5×10-5+40mHz) ±(5×10-5+40mHz) Frequency stability ±5×10-6/3 hours ±5×10-6/3 hours Amplitude Characteristics Amplitude range 2mVpp ~ 20Vpp (high impedance) 2mVpp~20Vpp 40mHz~10MHz (high impedance); 2mVpp~15Vpp 10MHz~15MHz (high impedance); 2mVpp~8Vpp 15MHz~20MHz (high impedance) Amplitude resolution 20mVpp (amplitude>2Vpp), 2mVpp (amplitude<2Vpp) Amplitude accuracy ±(1%+2mVrms) (high impedance, RMS, 1kHz) ±(1%+2mVrms) (high impedance, RMS, 1kHz) Amplitude stability ±0.5%/3 hours ±0.5%/3 hours Amplitude flatness ±5% (frequency<1MHz), ±10% (1MHz ~ 10MHz), ±5% (frequency<10MHz), ±20% (frequency between 10MHz ~ 60MHz) ±10% (frequency >10MHz) Output impedance 50Ω 50Ω Sine wave amplitude setting range (50Ω) 1mVpp ~ 10Vpp, when output frequency ≤10MHz; -- 1mVpp ~ 5Vpp, when output frequency ≤40MHz; 1mVpp ~ 2Vpp, when output frequency ≥ 40MHz; Amplitude setting range (high impedance) 2mVpp ~ 20Vpp, when output frequency ≤10MHz; -- 2mVpp ~ 10Vpp, when output frequency ≤40MHz; 2mVpp ~ 4Vpp, when output frequency ≥40MHz ; Offset Characteristics Offset range ±10V (high impedance) Resolution 20mVdc Offset accuracy ±(1%+20mVdc) Sweep Characteristics(linear sweep on frequency or amplitude) Sweep range free to set start point and stop point Sweep step any value more than resolution Sweep rate 10ms~60s/step Sweep mode Up, Down, Up-Down Manual sweep step/time Frequency Modulation Characteristics Modulation signal internal or external waveforms internal signal, channel B or external waveforms FM deviation 0%~20% 0%~20% Carrier signal -- channel A signal Amplitude Modulation Characteristics internal or external waveforms internal or external waveforms 0%~120% 0%~120% Shift Keying Characteristics FSK free to set carrier frequency and hop frequency ASK free to set carrier amplitude and hop amplitude PSK hop phase 0~360°, resolution 11.25° hop phase 0~360°, resolution 1° Alternative rate 10ms~60s 10ms~60s Output Characteristics of Channel B Waveform Characteristics Waveform type 32 kinds of waveforms, like sine, square, triangle, sawtooth, ladder etc. Waveform length 1024 points Sample rate 12.5MSa/s Waveform amplitude resolution 8bits Frequency Characteristics Frequency range Sine: 10mHz~1MHz; Other waveforms: 10mHz~100kHz Frequency resolution 10mHz Frequency accuracy ±(1×10-5+10mHz) Amplitude Characteristics Amplitude range 50mVpp~20Vpp (high impedance) Amplitude resolution 20mVpp Output impedance 50Ω Harmonic Characteristics (channel B frequency is the harmonic wave of channel A) Harmonic time 0.1 ~ 250.0 times -- Harmonic frequency <1MHz -- Phase adjustment coarse adjustment: 11.25 degree/step, fine adjustment: 2 degree/step -- Burst Characteristics(channel B signal is used as burst signal) Frequency of Channel B 40mHz ~ 1MHz Burst Frequency 10mHz ~ 50kHz Burst count 1~65000 cycles Burst mode continuous burst and single burst TTL Output Characteristics Waveform characteristics Square, rise/fall time≤20ns Frequency characteristics same as sine wave of channel A 10mHz~1MHz Amplitude characteristics TTL, CMOS compatible, low level<0.3V, high level>4V Common Characteristics Power source Voltage: AC220V (1±10%), AC110V (1±10%) (Pay attention to the position of voltage selection switch); Frequency: 50Hz (1±5%) Power: <45VA Environment Temperature: 0~40℃ Humidity: <80% Operation characteristics Key operation for all functions, menu display, rotary dial adjustment Display TFT display, 320*240, English, Chinese (simplified), Chinese (traditional) Mechanical 415mm×295mm×195mm; 3.5kg Manufacturing technology Surface Mount Technology, Integrated Circuit. High reliability and stability. Optional Parts Characteristics Frequency counter Testing frequency range: 1Hz~200MHz;Input signal amplitude: 100mVpp~20Vpp Max. output power: 7W (8Ω), 1W (50Ω) Max. output voltage: 22Vpp Power amplifier Frequency bandwidth: 1Hz-200kHz PAYPAL Only-Buyer must pay using PAYPAL ONLY within 7 days from the date of transaction made. Your order will be shipped within 1-2 business days once we receive your payment. Country Delivery Time Working Days 5-7 8-11 12-14 15-19 20-22 >22 Working Days Sat.+ Sun. 5-9 10-15 16-20 21-25 26-30 >31 United States Rate (Item Arrived) 5 .1% 50.1% 29.6% 10.5% 4.7% Refund United Kingdom Rate (Item Arrived) 9.9% 63.2% 19.1% 3.4% 4.4% Refund Australia Rate (Item Arrived) 21.4% 50.0% 14.3% 7.2% 7.1% Refund Canada Rate (Item Arrived) 0.0% 47.1% 31.4% 17.6% 3.9% Refund International Buyers–Please Note Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. These charges are normally collected by the delivering freight (shipping) company or when you pick the item up–do not confuse them for additional shipment charges. 60 days warranty from the purchased date. Please contact us via email before returning the defective item. For ensuring all the items are in good quality, we will test all products before the packages were sent out. Return items should include the original packaging and all accessories. Only defective product will be offered exchange. We will pay for the shipping cost of resending items, while buyers are responsible for the postal cost of returning the items. Please note that we are open Monday to Friday between 09:00 Am to 18:00 PM Beijing Time, which means we can keep on-line at: Our Working Schedule Bei Jing(CN) Monday to Friday 09:00 AM -18:00 AM New York(US) Sunday to Thursday 20:00 PM-05:00 AM London(UK) Monday to Friday 01:00 AM-10:00 AM Canberra(AU) Monday to Friday 11:00 AM-20:00 PM Engineered for professional eBay sellers! On Nov-24-14 at 00:55:38 PST, seller added the following information:
