Hantek 5in1 2ch 200ms/s60mhz Oscilloscope 16ch Logic Analyzer Arbitrary Waveform

US $3200

Fast Shipping From China, China
Oct 24th

Open on mobile:
QR code

Most U Want Dental Lab Supplies Store Category Handheld Oscilloscope Oscilloscope Probes Digital Oscilloscope Arbitrary Generator Logic Analyzer 5in1 Oscilloscope/Arbitrary Waveform Generator/Logic Analyzer/Spectrum Analysis/Frequency Counter 16 channels logic analyzer 2 Channel and EXT trigger 8--36V Wide range of input voltage, suitable for vehicle power test 25MHz arbitrary waveform output, (sine wave can deliver up to 75MHz) 200MSa/s DDS, 12bits of vertical resolution PC Based 200 MSa/s 2CH Digital Oscilloscope 60 MHz Bandwidth, With 16 channels logic analyzer Oscilloscope Mode Vertical System Analog Channels 2 Bandwidth 60MHz(-3dB) Rise Time 5.8ns Input Impedance Resistance: 1MΩ; Capacitance: 25 pF Input Sensitivity 10mV/div to 5V/div Input Coupling AC/DC/GND Vertical Resolution 8 bits Memory Depth 10K-16M/CH Maximum Input 400V (DC+AC Peak) Horizontal System Real-Time Sampling Rate 200MS/s Time BaseRange 5ns/div to 1000s/div(1-2-5 sequences) Time Base Precision ±50ppm Trigger System Source CH1, CH2, D0-D15, EXT Mode Edge,Pulse,Viedo,Alternative X-Y MODE X-Axis Input CH1 Y-Axis Input CH2 Phrase Shift Max.3 degree Cursors and Measurement Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency,Period, Rise Time, Fall Time, PositiveWidth, Negative Width, Duty Cycle Cursors Measurement Horizontal ,Vertical, Track, Auto Measure Modes Waveform Signal Process +,- , x,÷, FFT, Invert AUTO SET Yes Voltage Range 10mV to 5V/div @ x 1 probe; 100mV to 50V/div @ x 10 probe; 1V to 500V/div @ x 100 probe; 10V to 5000V/div @ x 1000 probe; 100V to 50000V/div @ x 10000 probe; 200mV to 100V/div @ 20:1 Current Range CC65(20A),CC65(60A),CC650,CC1100 FFT Rectangular, Hanning,Hamming, Blackman Window Math Adition, subtraction, multiplication, division Arb. Wavefrom Generator Mode Waveform Frequency DC~25MHz DAC 2K~200MHz adjustable Frequency Resolution 0.10% Channel 1CH waveform output Waveform Depth 4KSa Vertical Resolution 12 bit Frequency Stability <30ppm Wave Amplitude ±3.5V Max. Output Impedance 50 Ω Output Current 50mA Ipeak=50mA System BW 25M Harmonic Distortion -50dBc(1KHz), -40dBc(10KHz) Logic Analyzer Mode High input impendence 200K(C=10p) Input Voltage range -60V~60V Logic threshold range -6~6V Max Sample Rate 100MHz Bandwidth 10MHz Compatible input TTL, LVTTL, CMOS, LVCMOS,ECL, PECL, EIA Storage depth 10K-16M/CH General Features Interface USB 2.0(LAN Optional) Power Source 8-36V wide range of input voltage, suitable for vehicle power test. Volume 255 x 190 x 45 (mm) Weight 1kg Five-in-one PC Based Laboratories: Oscilloscope/Arbitrary Waveform Generator/Logic Analyzer/Spectrum Analysis/Frequency Counter Oscilloscope: 2 Channel and EXT trigger, 60MHz Bandwidth. 200MSa/s real-time sampling rate, 10k—16M memory depth per channel. Arbitrary Waveform Generator: 25MHz arbitrary waveform output, (sine wave can deliver up to 75MHz) 200MSa/s DDS, 12bits of vertical resolution. Frequency Counter, FFT spectrum analysis. 8--36V Wide range of input voltage, suitable for vehicle power test. USB 2.0 interface, LAN optional. More than 20 kinds of automatic measurement function, PASS/FAIL Check function, is suitable for engineering application. Excellent industrial design, similar interface with bench oscilloscope, easy to use. Software support: Windows NT, Windows 2000, Windows XP, VISTA, Win 7, Win 8. Supply DEMO code (VC, VB, LABVIEW) and technical support. One Year Manufacturer Warranty 1.The 5in1 Digital Oscilloscope 2.The Software and User Manual CD Package 4.High Frequency Probes 5.The USB cord. Click to view large picture Free Free Free 7-10 business days to be delivered. Other country please contact us for the shipping cost before your bidding. We always try our best to legally minimize your import duties (or GST or V.A.T. or other Taxes). In the most cases , there is no duty payable at all. However, if any additional charges generated for customs clearance must be borne by customers. ★Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. ★Please check with your country's customs office to determine what these additional costs will be prior to bidding / buying.These charges are normally collected by the delivering freight (shipping) company or when you pick the item up – do not confuse them for additional shipping charges. We always Value Your Satisfaction as the Most Important Thing! ! If, for any reason, you are not satisfied with your purchase,please don't be hesitate to let us know. This item is BRAND NEW in the original factory box.We provide full one year warranty for this item.
