Hardinge Hv-4n 5c Workholding Index Fixture / Indexer - Hardinge Thread Nose

US $1900

  • Covina, California, United States
  • Jun 2nd
Open on mobile:
QR code
Made in the U.S.A. by Hardinge. This is a used Horizontal / Vertical 5C Collet Indexing Fixture in GREAT condition. Model #: HV-4N Retails for $4,595.00 on the Hardinge website!! Features: Hardinge Collet Index Fixtures provide a quick and accuragte method of chucking and indexing work. Fixtures are planned to be applied interchangeably on the sub-base or on the table of milling machines, grinders, shapers, and drill presses. The spindle takes 1" capacity 5C Collets and has a hardened and ground index plate with 24 holes to give 15 degree spacings. Index holes and index pin have 8 degree included angle taper for positioning and locking. The index pin is spring backed for quick location in the index holes. In addition the HV-4N has a hardened and ground index plate with preselecting arrangement. A collet closer with 100 to 1 leverage to facilitate rapid chucking of work on a production basis. Ratchet device for rotating the spindle rapidly when indexing. Base for operation in either a horizontal or vertical position. Specifications: Spindle Type: 5C Nose Thread: 2-3/16" - 10 TPI Distance from Base to Center (set horizontally): 4" Base to Spindle Nose (set vertically): 8" Overall Dimensions (set horizontally): 10" x 8" x 8" tall Comes as shown in pictures. The lever arm will be removed for shipping purposes, and is easily reattached. I do my best to describe all items honestly and correctly. If you have an issue that seems to not coincide with my description, please contact me before opening a case, as to give me a chance to rectify any issue that may have arisen. Due to some issues in the past with customers buying an item, and then wanting to return it because it wasn't what they were looking for, I must charge a 20% restocking fee for instances such as this. Unless we agree on waiving said fee prior to the purchase of said item. So please ask any questions that you need prior to purchasing, or bidding on items. I would rather avoid these issues by communicating first. This restocking fee doesn't apply to items where I have made a mistake in the listing, and is the sole reason for the return, whether that be wrong dimensions, or damage. -155
