Heatcraft (r-k) Pvcl-400-ar

US $29.00

Oshkosh, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

Specifications Electrical Line Voltage: 110VAC to 600VAC, 3? Frequency: 60Hz, 300 Series 50Hz Line Voltage Ranges: 100 Series - 110VAC to 120VAC, 3? 200 Series - 208VAC to 240VAC, 3? 300 Series - 380VAC to 415VAC, 3? 400 Series - 440VAC to 480VAC, 3? 600 Series - 575VAC to 600VAC, 3? Maximum Overvoltage: 10% of highest nominal voltage Maximum Frequency Shift: 0.1Hz Undervoltage: 10% below set point Phase Imbalance: 5% typical Phase Rotation: A - B - C Phase Loss: Complete loss to 95% of nominal Time Delays: Pick-up: 5 Sec. Fixed Drop-out: 5 Sec. Fixed Operation The PVC’s output contacts energize when: 1. All the phases are present; 2. The voltages are within 10% of the setting; 3. The phases are in the proper rotation 4. The phases are balanced; 5. The frequency is within tolerance. Built into the PVC series is a 5 second pick-up delay to allow the three phase line to stabilize. If any of these conditions shift beyond the setpoints, the output contact will de-energize after a 5 second time delay. Single phase conditions will be detected when the voltage in one phase is 5% different from the voltages in the other two phases (Phase Imbalance).

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Item was professionally removed by Barr mechanical technicians in working order.”
