Hf2211 Wifi Serial Device Server Rs232 / 485 / 422+ Adaptor Serial Cable Antenna

US $49.03

, China
Aug 27th

Open on mobile:
QR code

HF2211 WiFi Serial Device Server RS232 / 485 / 422+ Adaptor Serial Cable Antenna Description: . Characteristic ² MIPS MCU with 4MB Flash and 8MB SRAM. Run on eCos ² Support TCP/IP/Telnet /Modbus TCP Protocol ² Support RS232/RS422/RS485 to Ethernet/Wi-Fi Conversion, Serial Speed Upto 230400 bps ² Support STA/AP/AP+STA Mode ² Support Router or Bridge Network Working Mode. ² Support 10/100M Ethernet Auto-Negotiation ² Support Easy Configuration Through a Web Interface or PC IOT Manager Tool ² Support Security Protocol Such As SSL/AES/DES3 ² Support Web OTA Wirelss Upgrade ² Wide DC Input 5~36VDC or 9~50VDC ² Size: 95 x65x 25 mm(Lx W x H) ² FCC_CE_RoHS_SRRC_REACH Certificated Features: Processor: MIPS Basic Frequency: 320MHz Flash: 4MB SDRAM: 8MB Operating System: eCos Ethernet Interface Standard: 1 RJ45 Rate: 10/100M Protection: 8KV Isolation Network Protocol: IPTCPUDPDHCPDNSHTTP Server/ClientARP, BOOTP, AutoIP, ICMPWeb socket, Telnet, FTP,TFTP, uPNP, NTP, SNMP,Modbus TCP Security Protocol: SSL v3 AES 128Bit DES3 Standard: 802.11 b/g/n Network Mode: STA/AP/STA+AP Access Terminal Quantity in AP Mode: Max 32 Transmit Power 802.11b: +20dBm(Max.) 802.11g: +18dBm(Max.) 802.11n: +15dBm(Max.) Receive Sensitivity: 802.11b: -89dBm 802.11g: -81dBm 802.11n: -71dBm Wi-Fi Security: WEP64/WEP128/TKIP/ AES Antenna Interface: 3dBi antenna Port Number: 1RS232/RS485/RS422 Interface Standard: RS232: DB9 RS485/RS422: 5.08mm connector Data Bits: 8 Stop Bit: 1,2 Check Bit: NoneEvenOdd Baud Rate: TTL: 300 bps~230400bps Flow Control: No Flow control Hardware RTS/CTSDSR/DTR Software Xon/ Xoffflow control Buffer: 4K Configuration: Web CLI XML import Telnet IOTManagerPC Software Virtual Serial: Windows, XP/Vista, 7 Server 2003/2008 Size: 95mm x 65mm x 25mm Operating Temp.: -25 ~ 85°C Storage Temp.: -45 ~ 105°C5 ~ 95% RHno condensation Input Voltage: 5~36VDC or 9~50VDC Working Current: ~200mA Power : <700mW Certificate: FCC_CE_RoHS_SRRC_REACH Warranty: 1 year Accessory List: 1* Power Adapter 1* Serial Cable 1* Ethernet Cable 1* WiFi Antenna

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Q-BAIHE
UPC	6256299531068
MPN	IOT-HF2211
EAN	6256299531068
