Hi-speed 100times/s Accuracy 0.1% Lcr Meter 5mhz Dc Bias Source Tftlcd Usb Lan

US $6,800.00

??, ???, China
Jan 29th

Open on mobile:
QR code

ZX8526, Test Frequencies: 20Hz-5MHz; Resolution, 1mHz. Features: 1.Hi-speed LCR meter, basic accuracy 0.1%, fast test speed(100times/second) 2. 10?CC, 25?, 50?, 100?, 10/100? output impedance 3. 800x480 resolution, TFT LCD 4. Test voltage and current auto balance adjustment(ALC) 5. 10 bins, can do statical quantity and percentage of pass 6. Fast correction, open and short circuit and load correction. 7. Keyboard lock function, power-off data protection 8. English and Chinese menu 9. Can store measuring data and settings(U disc or internal) 18. Graphic and frequence response characteristics scan function 11. Support U disc upgrade 12. Internal 50-group and U disc 500-group test files 13. U disc supports FAT16 and FAT32 14. RS232, USB TMC, USB CDC, Handler, LAN interfaces, GPIB(optional) 15. Internal rising edge? or falling edge? trigger 16. Internal DC bias -5V to +5V 17. BNC trigger on the back panel, can connect with external foot switch 18. Conform to LXI standards Specifications: Test parameter: C, L, X, B, R, G, D, Q, ESR, Rp, DCR, ?, |Y|, |Z|, TURN, P Basic accuracy: 0.1% Trigger: internal, external, manual, auto, bus Range: auto, keep Test signal level: 0.005-5Vrms(according to manual for details) Signal source output impedance: 10?CC, 25?, 50?, 100?, 10/100? output impedance Calibration: open/short circuit, full-frequency zero, frequency point zero Equivalent circuit: Series Parallel Comparator: 10 BINS, BIN0-BIN9,NG,AUX; Pass, Hi, Low(Pass/Fail LED display) Test speed: Fast, about 100 times/second; Mid, about 20 times/second; Slow, about 6 times/second Parameter Display Range L 0.0001uH-99999.9H C 0.0001pF-9.9999F R, X, |Z| 0.01m?-99.9999M? |Y|, B, G 0.0001uS-99.9999S D 0.0001-9.9999 Q 0.01-9999.9 DCR 0.1m?-99.999M? ?% -99.999%-99.999% Turns-Ratio 1:0.01-100:1 ? Deg -179.99°- 179.99° Rad -3.1416 - 3.1416 Temperature and Humidity: 0-40C,R.H.<=75% Power supply: 110-120Vac or 198-242Vac, 46-64Hz, power is more than 85VA, US, UK, AU, Euro power cord is available Size: 400mmx132mmx300mm Weight: 8.5Kg

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ZX8526
Country/Region of Manufacture	China
MPN	ZX8526
