High Power 10w Dc Input 9v-36v 1.5a Led Driver Buck Power Supply Pwm/dim

US $130

shenzhen, China
Feb 12th

Open on mobile:
QR code

[zipedit] Our-Store Home Page About Us Contact Us Add to Favourate Payment Shipping Return Payment Why Us Subscribe NewsLetter Add our store in to your favourites and recieve our exclusive emails about new items and special promotions Subscribe http://www.sure-electronics.net/mcu,display/LE-LL14113/LE-LL14113_2.jpg http://www.sure-electronics.net/mcu,display/LE-LL14113/LE-LL14113_2.jpg Product Overview Description High Power 10W 1.5A LED Driver PWM/DIM(LE-LL14113) Brief Introduction: New LED driver series are being released now. As the fifth member of the new series, this 10W LED driver is a dual-layer item which can be used directly to drive LEDs without requirement for extra converters. All components required are soldered on two minimized PCB, providing a cost-effective solution. This driver integrates an MBI6651chip (TO252 packaging) as the step-down DC-DC converter. It is a high efficient chip which is designed to deliver constant current to light up high power LED. Features of MBI6651 help make its applications safer, such as UVLO (under voltage lock out), over temperature protection, LED open-circuited protection and LED short-circuited protection. Moreover, thermal protection (TP) function has been introduced to protect IC from overheating (165°C) in various applications. Net weigt:32g /1.1oz Features: Size: 45.80(L) x 25.50(W) x 31.20(H) ±0.2mm Input voltage: 9V to 35V 84% efficiency @ input voltage 9V, 1 LEDs Typical 1626mA output current PWM frequency: 100HZ to 1KHZ Step-down DC/DC Constant current output TO252 packaging of MBI6651 helps heat dissipation Untested under conditions of more than 4 LEDs Allows users to control the dimming via an external PWM Easy installation and long service life LEDs vs Input Voltage: Number of LEDs 1 2 3 4 Input Voltage(V) 9-12 18-24 24-35 30-35 Pin Definition: Pin Description VIN Positive terminal for 9V-35V DC Power supply GND Power Ground LED+ Connect to the anode of LED LED- Connect to the cathode of LED EN PWM terminal. When applied with +5v or suspended, full amount of current will be output and when connected with ground, output current will be 0. Applications: Signage and Decorative LED Lighting Automotive LED Lighting High Power LED Lighting Constant Current Source Packing Including: High Power 10W LED Driver X 1 Note: The photos above are for reference only. Items you’ receive might be a little different from what you've seen on webpage since they might be from different batch. However, it won't affect your use. Sure Electronics assumes no liability for any ambiguity caused by the product photos. Payment Shipping 100% Success Refund & Return Home Page About Us Contact Us Add to Favourate Payment Shipping Return Designed By XDiom Graphics
