High Precision Cnc Touch Probe / Plate Edge Finder Conductive Workbee Router

GBP 29.95

Rochester, Hoo, United Kingdom
Jul 30th

Open on mobile:
QR code

High Precision CNC Touch Probe. Great for corner finding edge finding and XYZ offsets. -With the option of a protective case to keep your probe scratch-free, accurate and extend the life of your probe. Dimensions 50 X 50 X 15mm Measuring offset: XY:10mm +-0.05mm Z: 12mm +-0.05mm High Quality 6082 Aluminium - Guaranteed to stay precise a reliable for years 2 metres of Anti Noise Wire - This wire is used to stop false or early triggers keeping measurements precise Balanced Design - The design has been balanced to allow the probe to sit perfectly flat when corner finding. Magnetic Contact - Makes edge finding quicker and less of a hassle than crocodile clip contacts. Circular engraving on the top of probe for accurate 0 placement before probing Dispatched with Royal Mail 1st Class. FAQs 1. Which CNC's does this work with? The probe works with many different types of CNC machine and has the ability to be customised and used with different control boards. The main requirements are that you can provide the probe with 5 volts in one of the wires and place the second wire into your signal port/terminal. Your control board may either have a + and - for an input signal e.g., input +1 and -1 for live and ground for the input. Or it may have a 5V terminal to be shared amongst your different components and just a single terminal for an input that also acts as your ground terminal. In this case you want to wire to your 5V and the input terminal you want to assign to receive your signal. 2. Does it work with Mach 3/4/Grbl etc? Yes, the probe is compatible with Mach 3/4/Grbl etc. providing the settings are correct. e.g. Have you told the software which terminal the signal will be received? Before doing a live probing test on the machine it is always recommended to manual test with your hands first. As in using your hands make contact with the probe and check that you can visually see the signal is being received in the software. 3. Do you supply instructions so a non-technical person can get it to work? We do provide specific g code examples in a pdf, send a message after you have purchased, and we will send it to you. Specific instructions are not provided for wiring due to many machine variations on the market, but I am happy to provide support via eBay messages. The probe is a very simple system and essentially works like an on off switch which most people without experience can get the hang of quickly

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	United Kingdom
MPN	Does Not Apply
Material	Aluminium
Brand	Unbranded
