Hioki Pw3198 Power Quality Analyzer - Loaded With Options

US $5,550.00

Oceanside, California, United States
Jun 9th

Open on mobile:
QR code

HIOKI PW3198 POWER QUALITY ANALYZER *Call (760) 806-6600 to RENT this item* DESCRIPTION The Hioki PW3198 Power Quality Analyzer can measure all waveforms of power, harmonic, and error events simultaneously. When a problem occurs with the equipment or system on your site, the Hioki PW3198 will help you detect the cause of the problem early and solve it quickly. Features of the HIoki PW3198 Power Quality Analyzer include: Verify power problems in accordance with the IEC61000-4-30 Class A standard Easy Setup Function with PRESETS Just select the measurement course, wiring, and clamps Automatic one-step setup based on measurement conditions High Accuracy and continuous gapless recording (V:±0.1% of nominal voltage, A and W:±0.2% rdg. ±0.1% f.s.) CAT IV 600 V - safe enough for incoming power lines Broadband voltage range lets you measure even high-order harmonic components of up to 80 kHz Wide dynamic range from low voltages up to 1300 V (3P4W line-to-line voltage) Maximum 6000 V transient overvoltage up to 700 kHz LAN, USB and SD card interfaces Optional GPS BOX for synchronizing multiple devices Specifications of the Hioki PW3198 include: Measurement line type: Single-phase 2-wire, Single-phase 3-wire, Three-phase 3-wire or Three-phase 4-wire plus one extra input channel (must be synchronized to reference channel during AC/DC measurement) Voltage ranges: ?Voltage measurement: 600.00 V rms Transient measurement 6.0000 kV peak Current ranges: 500.00 mA to 5.0000 kA AC (depends on each current sensors) Basic accuracy: Voltage: ±0.1% of nominal voltage Current: ±0.2% rdg. ±0.1% f.s. + current sensor accuracy Active power: ±0.2% rdg. ±0.1% f.s. + current sensor accuracy Measurement Functions: Transient overvoltage: 2MHz sampling. Frequency cycle: Calculated as one cycle, 40 to 70Hz RMS voltage/ RMS current refreshed each half-cycle Voltage swell, Voltage dips, Voltage interruption Inrush current Voltage waveform comparison Instantaneous flicker value: As per IEC61000-4-15 Frequency: Calculated as 10 or 12 cycles, 40 to 70Hz 10-sec frequency: Calculated as the whole-cycle time during the specified 10s period, 40 to 70Hz Voltage waveform peak, Current waveform peak Voltage, Current, Active power, Apparent power, Reactive power, Active energy, Reactive energy, Power factor, Displacement power factor, Voltage unbalance factor, Current unbalance factor (negative-phase, zero-phase) High-order harmonic component (voltage/ current): 2kHz to 80kHz Harmonic/ Harmonic phase angle (voltage/ current), Harmonic power: 0th to 50th oders Harmonic voltage-current phase angle: 1th to 50th orders Total harmonic distortion factor (voltage/ current) Inter harmonic (voltage/ current): 0.5Hz to 49.5Hz K Factor (multiplication factor) IEC Flicker, ? V10 Flicker Configuration Notes: 9448 - Outlet Test Leads 9660 x3 - Three Clamp-On Sensor, 100A AC 9661 x3 - Three Current Clamp, 500A 9694 x3 - Three Clamp on Sensor, 5A AC C1001 - Soft Carry Case L100 - 4 Voltage Cables, 1 ea., red/yellow/blue/gray w/ 8 alligator clips PW9000 - Wiring Adapter for 3-phase, 3-wire *All of our equipment has been tested. Additional Calibration may be available upon request! ~Items sold with shown accessories, a power cord and manual on CD (when available)~ WARRANTY, PAYMENT, AND SHIPPING TERMS Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. And although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. All orders also come with a limited 5-day ROR (Right of Return). This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or an item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer, equipment that has been misused or damaged by customer's misuse (intentional or unintentional), or any orders damaged in transit. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your ownshipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.

“Equipment has been tested and is fully functional with a 30-day Warranty!”

Brand	HIOKI
Model	PW3198
