Hirschmann Spider 4tx/1fx-sm Eec Din Fiber Industrial Ethernet Switch 943880-001

US $70.00

Springville, Utah, United States
Jan 29th

Open on mobile:
QR code

These are used Hirschmann Spider 4TX/1FX-SM EEC, model 943880-001 (943 880-001). Four Fast Ethernet ports (10/100) and one fiber port (FX-SM). We prefer PayPal. USPS Priority Mail by default, but we will use any shipping method as requested and paid for by the buyer. Shipping weight 1 pound 5 ounces. The street price for this item is $500. These have been cleaned and thoroughly tested to make sure all ports are working as good as new. Included is the switch, fiber dust cover and three-pin power terminal. No original box, cables or instructions are included (everything you need is on the label anyway). We offer a 60-day no-questions-asked refund/replacement guarantee. 4 x 10/100BaseT(X) ports RJ45, Operating Temp. -40° to 70°C, Unmanaged Switch 1 x 100Base Single-Mode Fiber SC Connector Specification Description Model Description SPIDER 4TX/1FX-SM EEC 4 x 10/100BaseTX, 1 x 100BASE-FX, SM cables, SC sockets Interface Port 4 x 10/100BASE-TX, TP cable, RJ45 sockets, auto-crossing, auto-negotiation, auto-polarity. 1 x 100BASE-FX, SM cables, SC sockets. Fiber 100 BaseFX, SM (4TX/1FX), SC connector Power Supply / Signaling Contact 1 plug-in terminal block, 3-pin / no signal contact Network size - length of size Twisted Pair (TP) 0 - 100 m Single Mode Fiber Port 0-32,5 km, 16 dB link budget at 1300 nm, A = 0.4 dB/km, 3 dB reserve, D=3.5 (nm x km) Single Mode Fiber (SM) 9/125 µm 0 - 32,5 km, 16 dB Link Budget at 1300 nm, A = 0,4 dB/km, 3 dB Reserve, D = 3,5 ps/(nm x km) Network Size - Cascadibility Line - / star topology any Power Operating voltage 9,6 V DC - 32 V DC Current Consumption Max. 150 mA Power Consumption Max. 3,9 W 13,3 Btu (IT)/h at 24 V DC Service Management serial interface, web interface SNMP v1/v2/v3, HiVision Diagnostics LEDs (power, link status, data, data rate) Configuration functions terminal SW, BOOTP, DHCP, DHCP option 82, auto-configuration adapter (ACA 11), HiDiscovery Security SNMPv3 Environmental Operating Temperature -40 ?C to + 70 ?C Storage Temperature -40 ?C to +70 ?C Relative Humidity 10% to 95% MTBF 93.9 years; MIL-HDBK 217F: Gb 25 ?C Other Servies priorisation (IEEE 802.1D/p), broadcastlimiter, SNTP (simple network time protocol), flow control (IEEE 802.3) Mechanical Dimensions (W x H x D) 25 mm x 114 mm x 79 mm Mounting DIN Rail 35 mm Weight 120 g Protection IP 30 Mechanical Stability IEC 60068-2-27 Shock 15 g, 11 ms duration, 18 shocks IEC 60068-2-6 Vibration 3.5 mm, 3 Hz - 9 Hz, 10 cycles, 1 octave/min.; 1g, 9 Hz - 150 Hz, 10 cycles, 1 octave/min. Redundancy functions HIPER-Ring (ring structure), RSTP (rapid spanning tree protocol), redundant network/ring coupling (receiver functionality), dual homing (receiver functionality), redundant 24 V power supply EMC Interference Immunity EN 61000-4-2 electrostatic discharge (ESD) 6 kV contact discharge, 8 kV air discharge EN 61000-4-3 electromagnetic field 10 V/m (80 - 1000 MHz) EN 61000-4-4 fast transients (burst) 2 kV power line, 1 kV data line EN 61000-4-5 surge voltage power line: 2 kV (linie/earth), 1 kV (linie/line), 1 kV data line EN 61000-4-6 conducted immunity 10 V (150 kHz - 80 kHz) Agency Approvals FCC FCC CFR47 Part 15 Class A EMI EN 55022 Class A CUL cUL 508 (E175531) Hazardous Location cUL 1604 Class 1 Div 2 (E203960) Germanischer Lloyd Germanischer Lloyd (15 662 - 00 HH) Scope of Delivery and Accessories Scope of Delivery device, terminal block, operating manual Accessories to Order Separately rail power supply RPS 30, RPS 60 or RPS 120, 19" installation frame

Condition	Seller refurbished : An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes	“Cleaned, tested (works like new) and 60-day no-questions-asked guarantee.”
