Irschmann Spider Ii 8tx/2fx-sm Eec Din Fiber Industrial Ethernet 943958-231

US $85.00

Springville, Utah, United States
Jan 29th

Open on mobile:
QR code

These are used Hirschmann Spider II 8TX/2FX-SM EEC, model 943958-231 (943 958-231). Eight Fast Ethernet ports (10/100) and two fiber ports (FX-SM). We prefer PayPal. USPS Priority Mail by default, but we will use any shipping method as requested and paid for by the buyer. Shipping weight 1 pound 5 ounces. The street price for this item is $810. These have been cleaned and thoroughly tested to make sure all ports are working as good as new. Included is the switch, fiber dust cover and three-pin power terminal. No original box or instructions are included (everything you need is on the label anyway). We offer a 60-day no-questions-asked refund/replacement guarantee. 8 x 10/100BaseT(X) ports RJ45, Operating Temp. -40° to 70°C, Unmanaged Switch 2 x 100Base Single-Mode Fiber SC Connector Specification Description Product description Description Entry Level Industrial ETHERNET Rail-Switch, store and forward switching mode, Ethernet (10 Mbit/s) and Fast-Ethernet (100 Mbit/s) Port type and quantity 8 x 10/100BASE-TX, TP-cable, RJ45 sockets, auto-crossing, auto-negotiation, auto-polarity, 1 x 100BASE-FX, SM-cable, ST sockets More Interfaces Power Supply / Signaling Contact 1 plug-in terminal block, 3-pin, no signaling contact Network size - length of cable Twisted Pair (TP) 0 - 100 m Network Size - Cascadibility Line - / star topology Any Power Requirements Operating voltage DC 9.6 V - 32 V Current consumption at 24 V DC max. 275 mA Power Consumption max. 7 W 23.9 Btu(IT)/h Service Diagnostics LEDs (power, link status, data, data rate) Ambient conditions Operating Temperature -40 ?C to +70 ?C Storage Temperature -40 ?C to +85 ?C Relative Humidity 10% to 95% MTBF 58.7 years MIL-HDBK 217F: Gb 25?C Mechanical Construction Dimensions (W x H x D) 35 mm x 138mm x 121 mm Mounting DIN Rail 35 mm Weight 253 g Protection IP 30 Mechanical Stability IEC 60068-2-27 Shock 15 g, 11 ms duration, 18 shocks IEC 60068-2-6 Vibration 3,5 mm, 3 Hz - 9 Hz, 10 cycles, 1 octave/min.; 1g, 9 Hz - 150 Hz, 10 cycles, 1 octave/min. EMC Interference Immunity EN 61000-4-2 electrostatic discharge (ESD) 6 kV contact discharge, 8 kV air discharge EN 61000-4-3 electromagnetic field 10 V/m (80 - 1000 MHz) EN 61000-4-4 fast transients (burst) 2 kV power line, 4 kV data line EN 61000-4-5 surge voltage power line: 2 kV (linie/earth), 1 kV (linie/line), 1 kV data line EN 61000-4-6 conducted immunity 10 V (150 kHz - 80 kHz) EMC emitted immunity FCC CFR47 Part 15 FCC CFR47 Part 15 Class A EN 55022 EN 55022 Class A Agency Approvals Safety cUL 508 (E175531) pending Scope of Delivery and Accessories Scope of Delivery Device, terminal block, operating manual Accessories to Order Separately Rail power pupply RPS 30, RPS 80 EEC or RPS 120 EEC, 19" installation frame

Condition	Seller refurbished : An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes	“Cleaned, tested (works like new) and 60-day no-questions-asked guarantee.”
