Hp 8660c Synthesized Signal Gen + 86603a/86633b + 3 Op/serv Manuals/schematics

US $775.00

Cupertino, California, United States
Jan 29th

Open on mobile:
QR code

Selling the following: 1) HP 8660C Synthesized Signal Generator Option 001/005 s/n:1846A02073 2) HP 86633B Modulation Section AM-FM s/n: 1857A00989 3) HP 86603A RF Section 1-2600 MHz s/n: 1816A01121 4) HP 8660C Operating/Service Manual contains schematics 5) HP 86633B Operating/Service Manual contains schematics 6) HP 86603A Operating/Service Manual contains schematics No cables (power, RF, or communication) are shipping with the unit. Exterior of unit is a bit scuffed up and dirty. I noticed a dent on the top out side to the left of the vent hole. It is protruding up from the top. All feet are intact. Tests Performed: 1) System powers up. 2) For the 886603A Operators check on page 3-5: Set the Modulation section to off, and 8660C center frequency to 500 MHz. 88603A set Vernier 437B power Meter measurement 0 dBm +3 dBm 3.83 dBm 10 dBm -3 dBm 7.79 dBm Not sure if power meter is calibrated; RF section did put out RF power 3) Sent the RF out put into a 8562E Spectrum Analyzer Set Point 8660C 8562E measurement from RF section 86603A 1 GHz 997.7 MHz 1.2 GHz 1.1983 GHz 2.0 GHz 1.9953 GHz 2.6 GHz 2.5957 GHz single peak (see picture) 4) With RF Modulator turned on: 8660C set at 100MHz, RF Modulator set at X1 400 internal 90%: Modulated signal could be observed on the spectrum analyzer. Shipping: System is very heavy: 73 pounds for 8660C + 3 modules. 7 pounds for the manuals. As a result, the unit and manuals will ship in two packages via UPS to the 48 continental USA states ONLY. No PO Boxes. UPS does not ship to PO Boxes. I am over-estimating the shipping weight by 10 pounds to compensate for the added cost of shipping two packages. eBay does not calculate shipping costs properly on multiple packages. Buyer: BEFORE PURCHASING UNIT contact me with approximate address so that I can refine the shipping costs and adjust the invoice accordingly. Please Pay with Paypal within 24 hours of offer acceptance. I will ship after payment is receive. I sell these items part time. I try to respond quickly; but since it is part time, sometimes my response is slow. We all make mistakes, If you mistakenly won a bid for this item, please do not wait 4 days to contact me. Please do so quickly so that we can cancel the transaction. If the item has been shipped, it becomes more costly, complicated, and time consuming to cancel. Thank You, sanvickeb.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Functional. Tested RF output into a 8652E spectrum analyzer and 437B power meter, check pictures and details section.”
