Hy Series 3-phase 4kw Variable Frequency Drive Vfd Inverter Spwm 380vac

US $187.00

Shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

template HY series 3-phase 4KW Variable Frequency Drive VFD Inverter SPWM 380VAC Fast shpping DHL / EMS / Fedex Application: Metallurgy, petroleum, chemical, textile, electricity, building material, coal, medicine, food, paper making, plastic, printing, lifting, cable, washing, water supply, HVAC, sewage disposal and other industries Machinery:winding machine,mixter,extruder,slitter,winder,compressor,ventilator,pump,grinder,convegor,elevator,centrifuge and other 1. PID control:advanced calculous PID closed-loop arithmetic,quick responding speed and high suitability 2. Easy PLC function can realize 16 legs of speed and inverter control function 3. RS485 communication port,adopting standard international MODBUS main circuit control 4. With extremely strong anti-jamming capability 5. Low output ratting torque 0.5HZ-150%,low speed running ability 6. Carrier adjustable by 16KHZ,completely soundless working environment 7. Broad voltage working area,normal running in 304-456V 8. Auto voltage regulation(AVR) technique,for ensuring the inverter load capability 9. Various control technique by both synchronization and non-synchronization,dynamically realize fast starting without changing brakes 10. With perfect error protection and short circuit starting protection capability 11. Dead-time compensation and auto torque slip compensation function,can realize 180% high torque output at low frequency 0.25Hz 12. Unique EMC design,can minimize inverter’s pollution to power 13. Overall reinforcement layer to suit all kinds of harsh environment General specification: Control mode SPWM Input power 330-400V 5-Digits display&status indicator lamp Displaying frequency,current,revolution,voltage,counter,temperature,forward or reserve running,and fault,etc Communication control RS-485 Operation Temperature -10~40°C Humidity 0-95% Relative Humidity(without dew) Vibration Below 0.5G Range(Frequeny control ) 0.01-400.00Hz Accuracy(Frequency control) Digital:0.01%(-10~40°C),Analog:0.1%(25±10°C) Setting Resolution(Frequency control) Digital:0.01Hz,Analog:1/1000 of Max.Operating Frequency Output Resolution(Frequency control) 0.01Hz Operator setting method(Frequency control) Press up and down to set Analog setting method(Frequency control) External Voltage 0-5V,0-10V,4-20mA,0-20mA Other function(Frequency control) Frequency lower limit,starting frequency,stopping frequency,three skip frequencies can be respectively set Ramp control(General control) Selectable 4-speed steps ramp-up and down time(0.1-6500s) V/F Curve Set V/F curve at will Torque control Torque increase is settable by max.10.0%,The starting torque can reach 150% at 1.0Hz Multi-inputs(General control) 6 multi-function input terminals for 8-speed steps control,program operation,switching of 4-speed Ramp,Up,down function,counter,external emergency stop and other functions Multi-output(General control) 5 multi-function output terminals for displaying of running,zero speed,counter,external abnormity,program operation and other information and warnings Other functions(General control) AVR(Auto voltage regulation),deceleration stop or free-stop,DC brake,auto reset and restart,frequency track,PLC control,traverse function,drawing control,auto energy-savings,carrier adjustable by max,20KHz,etc Overload protection(Protection function) Electronic relay protection motor Drive(for constant torque 150%/1 min.for the kinds of fan 120%/1 min) Fuse protection(Protection function) Fuse broken,motor stops Over-voltage(Protection function) DC Voltage>800V for 380V class Low voltage(Protection function) DC Voltage
