IDS Blue Box - Breakout Box and Cable Tester, US $25.00 – Picture 0
IDS Blue Box - Breakout Box and Cable Tester, US $25.00 – Picture 0

Ids Blue Box - Breakout Box And Cable Tester

US $25.00

  • White Plains, New York, United States
  • Feb 12th
Open on mobile:
QR code
Used for testing and configuring RS-232 cables The BLUE BOX 100 Breakout Box and Cable Tester is a portable, hand-held test set that can be used to access and monitor all the conductors on any interface that can be plugged into a 25-pin, D-type connector such as RS-232-C, EIA-232-D, and CCITT V.224.  Pairs of Red and Green LEDs are used for monitoring the state of each interface signal.. All of the signals can be interrupted to allow for cross-patching.  There is one pair of LEDs for each of the 25 conductors on both the DTE and DCE sides of the unit, for a total of 50 pairs (or 100 LEDs).  The unit also provides outputs of +/-9V for setting any undriven signal to a high or low level.  Other features provided by the BLUE BOX 100 include 3 kio ohm resistive loads, control signal switches, and various connections of data signals.  The unit can also be used for checking the configuration of cables.  All shorted leads, open leads, and miswired leads can be tested.
