Injection Mold Base 10 X 10 7075 Aluminum Prototype Plastic Polymer

US $1,697.00

Hamilton, Ohio, United States
Jan 30th

Open on mobile:
QR code

The aluminum injection mold base (pictured is 8 x 10) for sale is a precisely machine 10 x 10 B style. A&B plate material is 7075 T6 aluminum Other dimensions (in inches) are as follows: A&B plates L x W x H 10.00 x 10.00 x 3.44 Other thicknesses available in stock Clamp plates A & B - .87 thick Ejection stroke – 1.7 (higher rails available) Ejector plate -.87 x 7.0 x 10.0 Retainer plate .63 x 7.0 x 10.0 Total thickness – 10.76 4- 3/4 dia. pins -1 pin offset Approx. weight – 125 lbs with pkg. Buy this same mold design in many other sizes - contact us for a fast quote!!!! Lowest Prices in the USA for Aluminum Mold Bases - many sizes ready to ship!!! High Quality A and B style mold bases – shipped directly to your shop from ours….Machined from 7075 T6, ALUMOLD and QC10 aluminum….We build into our bases the features that are characteristic of all well made molds ….. Heat treated Leader pins and bushings….Vented leader pins….Pry slots between plates….Beveled edges on corners …Ground parting line surface….Three piece bolted ejector housing....Return pins installed….Eyebolt holes...Tubular dowel construction on A style…AND ….Proudly made in the USA. Hundreds of thousands of production shots achievable! One major OEM supplier boasts of 600K shots on their 7075 aluminum production molds. And still producing good parts ! Additional details: Note: Delivery on this mold can be 3-5 days if we are out of shelf stock All the plates are parallel and square within .001 and the thickness is parallel within .0015 after assembly and the parting line ground A 3D file furnished with purchase. We also have other sizes along with MUD inserts and will send a price list or quote a special size upon request. Get more info at www.aqmolds.com or email aqmolds1@gmail.com See 7075 T651 aluminum specs here-Brinell Hardness = 150 : http://asm.matweb.com/search/SpecificMaterial.asp?bassnum=MA7075T6 10% of your purchase will go to needy countries to feed the poor, cloth the naked and give shelter to the homeless.
