Inno Ifs-10 Fusion Splicer & Odm Ttk 500 Sm & Mm Test Kit 1310/1550 & 850/1300

US $11,400.00

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Item may require 7 to 14 days lead time. Fiber Optic Loss Test Kit with VIS 300 connector inspection monitor/probe, single mode and multimode light sources, power meter, battery kit, cables, connectors, software, case and cleaning. IFS-10 fusion splicer with VF-78B Cleaver, splicing accessories, fiber optic cleaning kit, fiber strippers and 500 splice protection sleeves. This combo pairs INNO Instrument's New Core Alignment IFS-10 Fusion Splicer with ODM's TTK 500 Single-mode/Multi-mode Optical Loss Test Set. Splice single fibers fast using the IFS-10 splicer then test using the accurate TTK-500 kit all while saving money. Manufacturer Description IFS-10 2.2kg weight (without Battery) Harsh weather conditions adaptability Friendly smart GUI Large Battery capacity: 350 splice & heat cycles Quick optimize menu High precision splicing USB master port, easy to upgrade software Operate in Bi-directional view INNO Instrument 3-Year Warranty The INNO Instrument IFS fusion splicer models include a three-year warranty against manufacturer's defects. For a period of three-years defective materials will be repaired or replaced. Wearable items such as battery and electrodes are not covered. No warranty is expressed or implied regarding damage resulting from consumer misuse or neglect or for any consequential damages arising out of the use of this product. Physical damage, improper use, and shipping are not covered under any warranty. TTK 500 TTK 500 is configured for Video Inspection with USB for data download to your computer. • RP 460 power meter with streaming data software • DLS 350 LED light source • DLS 355 Laser light source • The kit is also equipped with cables, adapters and cleaning items for both single mode and multimode testing. • VIS Image Manager Software included to create Loss Reports. IFS-10 Splicing Method: Core alignment (DACAS:Digital Analysis Core Alignment System) Average loss: SM(0.02dB) | MM(0.01dB) | DS(0.04dB) | NZDS(0.04dB) Return loss >> 60 dB Splice time: 9s average SM | 7s SM Quick Mode Pull test: 1.96~2.25N (standard) Electrode Lifespan: > 2,500 arcs Applicable fiber: SM(ITU-TU.652), MM(ITU-TU.651), DS(ITU-T G.653),NZDS(ITU-T G.655), G657A, G657B Cleaved length: Coating diameter < 0.25mm = 8-16mm Coating diameter > 0.25mm = 16mm minimum Coating Diameter: 100-1000um Cladding Diameter: 80-150um Heating programs: Preset 10 heating modes Heating time: FP-03 typical heating time 35s Protection sleeve: 10mm, 20mm, 30mm, 40mm, 50mm, 60mm Data output: USB master device and COM Splice Programs: 100 user mode Splice Memory: Up to 2000 records Battery: Typical full cycle 350 times Power supply: AC 100-240V input or DC 18V Monitor: Color 5" LCD monitor, with tempered glass Cameras: 2 CCD camera system Magnification: XY style: 150 power, X/Y: 300 power Fiber Display: X/Y or XY, single X.Y Weight: 2.2KG (without battery) Size: 155 x 130 x 143mm (excluding rubber bumper) Wind protection: The max wind speed 15m/s Operating environment: Elevation 0-5000 meters, -10~50°C, ~95% relative humidity Storage Condition: Temperature -40 to 80°C, ~95% relative humidity TTK-500 Resolution .01dB Dynamic Range 60dB Single Mode Dual 1310/1550nm Multi Mode Dual 850/1300nm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	INNO Instrument
Fusion Splicer Options	Stripper and more
Model	IFS-10
Splicing Capabilities	Core Alignment
Item Application	Fiber Optic Cable OTDR
Splice Memory	2000 records
Wavelength	850, 1300, 1310, 1550nm
Splicer Power Required	AC 100-240V
Equipment Class	Battery
Manufacturer	ODM
Battery Life Cycle	350 times
Splice Time	9 sec
Fiber Display	X/Y OR XY, Single X Y
