Jdsu T-berd 6000 8126 Vsre Sm Fiber Otdr W/ Power Meter & Vfl 8126-vsre

US $4,895.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: JDSU T-BERD 6000 Compact Optical Test Platform Mainframe (BC# 19170) Power Meter: 850nm 980nm 1300nm 1310nm 1420nm 1450nm 1460nm 1490nm 1510nm 1550nm 1625nm 1650nm VFL JDSU 8126VSRe SingleMode OTDR Module (BC# 19223) SM OTDR Source: 1310nm 1550nm SC Connector For Source Ethernet Cable (2) SM SC-SC Fiber Cables OTDR DWDM Insertion Loss CD (4) Fiber Optic Wipes AC Adapter/Charger Power Cord User Manual On CD-ROM Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! JDSU T-BERD 6000 Compact Optical Test Platform Mainframe w/ Power Meter & VFL & JDSU 8126 VSRe Singlemode 1310 / 1550nm OTDR Module Power Meter: - 850nm - 980nm - 1300nm - 1310nm - 1420nm - 1450nm - 1460nm - 1490nm - 1510nm - 1550nm - 1625nm - 1650nm Dynamic Range: 1310 / 1550nm : 32 / 30dB Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty JDSU T-BERD 6000 Compact Optical Test Platform Mainframe Key Features: Compact, lightweight, and highly integrated platform More than 40 application modules already supported for, multimode and single-mode Built-in VFL, power meter, LTS, ORL, and video inspection, scope options Choose from IL/ORL,OTDR,PMD,CD, AP and/or WDM, plug-ins Exceeds Telcordia specifications for ruggedness, drop, testing, and extended battery life Compatible with plug-in modules from the MTS-51001, and T-BERD 8000 Applications Performs multimode and, single-mode OTDR and optical loss, test (bidirectional) Conducts connector inspection and, continuity testing Finds faults and identifies traffic Tests FTTx/PON and CWDM, networks Performs fiber dispersion testing, (PMD/CD/AP) for 10G/10GE/40G Allows for use of talk set/data port, for automated end-to-end, communication and unit control Generates proof-of-performance, reports The JDSU T-BERD 6000 is a highly integrated test platform designed for all, phases of the fiber network life cycle. It provides field service technicians with the, highest levels of performance and upgradeability on the market today. The modular design of the T-BERD 6000 offers an extensive portfolio of test, functionality with over 40 different fiber modules supporting a wide range of, applications. The versatility of the T-BERD 6000 allows technicians to standardize, using one type of test equipment and then introduce new testing capabilities in, the field without incurring additional training or device costs. The T-BERD 6000 is compatible with our existing fiber module product line, so, technicians can exchange plug-in modules between the T-BERD-8000 Scalable, Optical Test Platform and the T-BERD 6000, in the field and without the need for, additional tools. To ensure the highest level of return on your capital investment, for test equipment, an extension allows you to upgrade existing OTDR modules, from the MTS-5100 for use with the T-BERD 6000. To ensure the highest-level return on investment for your test equipment, upgrade, existing optical time domain reflectometer (OTDR) modules from the MTS-5100, (with an extension) for use with the T-BERD 6000. Ideal for Field Testing The T-BERD 6000 is a highly integrated platform with a single module slot and, the option to extend internal memory up to 1 gigabyte. The platform features an, intuitive graphical user interface (GUI) shown on a large 8.4 inch transreflective, color display (with an optional touchscreen) to improve viewing under any, condition. The high capacity Lithium ion battery adds extended life. Other, features include an optional video inspection scope (via USB port), and optional, built-in optical test functions, such as a visual fault locator (VFL), power meter,, optical return loss (ORL) and loss test sets (LTS). The T-BERD 6000 also has a, built-in optical talk set option for communicating and controlling remote units, along the fiber, and it can transfer data fast using the USB or Ethernet port. Overview of Fiber Optic Applications Compact and Highly Integrated The versatility of the T-BERD 6000 allows it to address premises to long-haul, networks comprising new technologies, such as various fiber networks (FTTx),, remote optical add/drop multiplexers (ROADMs), and 40 G. Built-in VFL, laser source power meter, LTS, talk set/data, and video inspection, scope options (simultaneously) Bidirectional insertion loss (IL) and ORL capabilities combined in one module OTDR and chromatic dispersion (CD) capabilities combined in one module Polarization mode dispersion (PMD), wave division multiplexing (WDM), and, attenuation profile (AP) capabilities combined in one module PMD, CD, and AP capabilities combined in one module Wide Range of Test Applications LAN/WAN Premises – 10 GigE local area network (LAN) qualification Solution: T-BERD 6000 with the unique universal SRL 850/1300/1310/1550/1625 nm OTDR Module FTTx/Access Networks – End-to-end connectivity on point-to-point networks, including sectionalized, testing on a passive optical network (PON) (without a splitter, Solution: T-BERD 6000 with the VSRe, SRe,MR OTDR module at 1310/1550 nm – End-to-end connectivity on PONs, including splitter qualification Solution: T-BERD 6000 with the MR, LR, or VLR at 1310/1490/1550 nm OTDR, module Add optional VFL, power meter, and video inspection scope – In-service maintenance and troubleshooting without service disruption Solution: T-BERD 6000 with the filtered LR OTDR module at 1625 nm Metro/Core Networks – End-to-end connectivity and fiber splice qualification Solution: T-BERD 6000 with the MR, LR, or VLR at 1310/1550/1625 nm OTDR module Add optional VFL, power meter, and video inspection scope Ultralong-Haul Networks – End-to-end connectivity and fiber splice qualification Solution: T-BERD 6000 with the UHD OTDR m 10G/40G Fiber Characterization – Characterize fiber in high-speed transmission systems for loss/dispersion Solution: T-BERD 6000 with the PMD/CD/AP, ODTR, and OFI module CWDM/DWDM – Characterize fiber and prove suitability to carry multiple channels (water peak) Solution: T-BERD 6000 with the VLR OTDR module at 1383 nm Add the combined PMD/WDM/SA or CDWM OTDR module Modular Platform – New technologies developed in the future Solution: T-BERD 6000 with the new JDSU field-upgradeable application module OTDR and IL/ORL Testing A Wide Range of OTDR Modules The JDSU OTDR plug-in module family provides a wide range of highperformance, OTDRs. Over 40 field-interchangeable modules are compatible with, the T-BERD 6000 for testing and troubleshooting any multimode or single-mode, network. The OTDR family includes six lines of OTDRs featuring: New wavelengths to cover 1383 nm (CWDM) and 1490 nm (FTTx) Highest dynamic range up to 50 dB Shortest dead zones down to 0.5 m in multimode and 0.8 m in singlemode Fastest scan speed at 0.1 s in real-time mode From Simple Fault Locator to Expert OTDR… The fault locator boosts productivity in the field by providing: Fast detection Precise fault location One-button automation No specific settings required Distance, loss, and ORL measurements The expert mode offers high-level trace analysis possibilities, making your, T-BERD 6000 platform a powerful instrument for commissioning and troubleshooting, by offering: Manual settings (pulse, acquisition time, resolution, distance range) Manual addition and deletion of events Manual slopes, splices, and reflectances measurement Ideal for End-to-End Commissioning OTDR bidirectional testing is required to obtain true and accurate splice loss, readings. JDSU has developed an innovative automatic bidirectional analysis, function that is integrated directly into the T-BERD 6000 platform, saving at least, 50 percent of the time required for traditional bidirectional analysis. Offers communication between two units via the link under test to set up the, same optimized acquisition parameters Displays and saves automatic acquisitions in both directions on both units Eliminates operator error CWDM OTDR Modules The CWDM OTDR module allows in-service OTDR measurements at, International Telecommunications Union (ITU-T) G.694.2 CWDM wavelengths. This solution was developed to help network operators and dark fiber providers, characterize, maintain, and troubleshoot CWDM systems from short- to mediumhaul, fiber networks. FTTx/PON In-Service Modules To avoid interrupting customer traffic (in-service testing) of B/G/E-PON, networks the filtered OTDR module performs an out-of-band test using 1625 nm, wavelength. Insertion Loss and Optical Return Loss Testing Measures bidirectional IL, ORL, and fiber length Offers one-button automated testing Choose three wavelengths from 1310, 1490, 1550, and 1625 nm Compatible with the OFI-2000 Multifunction Loss Test Set CD,PMD,AP, and WDM Testing The T-BERD 6000 enables CD and PMD measurements to identify fiber viability, for very high-speed transmission systems. It also enables WDM and AP tests to, validate the link compatibility with DWDM system implementation. Polarization Mode Dispersion Testing Fast and accurately measures PMD delay, PMD coefficient, and, second-order values Offers high dynamic range (up to 65 dB) dedicated for metropolitan, long haul,, and very long haul fiber optic links Offers shock- and vibration-proof design (with no moving parts) Allows for measurement through multiple amplifiers Provides statistics and long-term monitoring Chromatic Dispersion Testing - OTDR-Based Method Requires access to only one end of the fiber Offers dynamic range (up to 120 km) dedicated for any metropolitan fiber optic, links Includes acquisition points around 1310, 1480, 1550, and 1625 nm for accurate, CD from 1260 to 1650 nm Integrates a four-wavelength OTDR and light source Provides sectional analysis capability for troubleshooting Offers shock- and vibration-proof design (with no moving parts) Chromatic Dispersion Testing - Phase-Shift Method Offers high dynamic range (up to 55 dB) dedicated for metropolitan, long haul,, and very long haul fiber optic links Provides full wavelength range characterization (1260 to 1640 nm) Allows for measurement through multiple amplifiers Offers shock- and vibration-proof design (with no moving parts) Attenuation Profile Testing Provides total loss and dB/km values for full band testing (1260 to 1640 nm) Allows CDWM and dense wavelength division multiplexing (DWDM), transmission band characterization Provides water peak (1383 nm area) characterization Offers shock- and vibration-proof design (with no moving parts) Combined with WDM and PMD functions or with CD and PMD functions DWDM Maintenance Testing Measures channel level, power, and wavelength in the S, C, and L bands Provides the most compact DWDM test solution that measures optical signalto-, noise ratio (OSNR) Tests wavelengths from 1260 to 1640 nm or 1485 to 1640 nm Offers high wavelength accuracy Provides statistics and long-term monitoring Offers shock- and vibration-proof design (with no moving parts) Specifications Specifications for Typical 25°C Display TFT color, 8.4 in LCD, 800 x 600, high-visibility (standard) Touchscreen,TFT color, 8.4 in LCD, 800 x 600, high-visibility (optional) Storage and I/O Interfaces Internal memory 1000 test results Extended memory (optional) Minimum 1 GB (optional) 2x USB V1.1, 1x RJ45 Ethernet Power Supply Battery type Standard removable Li-ion batteries AC/DC adapter Input 100–240 V, 50–60 Hz, Output 19 V DC/3.1 A Operation time Up to 11 hrs with standard display, Telcordia GR-196-CORE Size and Weight Mainframe with one plug-in module and battery (L x H x W) 285 x 195 x 93 mm (11.2 x 7.7 x 3.7 in) Mainframe only (without battery and module) 2.4 kg (5.3 lb) Mainframe (with one plug-in module and battery) 3.4 kg (7.5 lb) Environmental Specifications Operating temperature range on mains (no options) –20 to +50°C (–4 to 122°F) Operating temperature range (all options) 0 to +40°C (32 to 104°F) Storage temperature range –20 to +60°C (–4 to 140°F) Humidity, non-condensing 95% Base Unit Optical Interfaces (optional) Power Meter Power level +10 to –60 dBm Calibrated wavelengths 850, 1310, and 1550 nm Connector type Universal push/pull (UPP Talkset Wavelength 1550 nm ±20 nm Dynamic range 45 dB Function With data/file transfer Laser safety Class 1M laser Connector type Field interchangeable Optical Return Loss Selectable wavelength 1310 / 1550 nm Measurement range 0 dB to 45 dB Measurement uncertainty ± 1 dB Display resolution 0.01 dB Visual Fault Locator Wavelength 635 nm ±15 nm Output power level <1 mW Laser safety Class 2 laser Connector type Universal push/pull (UPP) Continuous Wave Light Source Wavelengths (selection) 1310, 1550, and 1625 nm Output power level –3.5 dBm Stability in 15 min ± 0.02 dB Stability in 8 hrs ± 0.2 dB Laser safety Class 1M laser Connector type Field interchangeable Video Inspection Scope (via USB) Magnification 250X and 400X, through the USB port 8126 VSRE Singlemode OTDR Module The new JDSU Very Short Range (VSRe) OTDR Module for the MTS/T-Berd 8000 and MTS/T-Berd 6000 product platforms provides the needed performance with maximum efficiency for any access/FTTx/Metro network test application. In the telecommunication market of today, OTDR est solutions must be cost-effective, easy-to-operate and flexible for optimum use in all testing conditions. The VSRe PTDR module meets these challenges for both present and future needs. The MTS/T-Berd product line has built a solid worldwide reputation based on cutting-edge design and performance. Compatibility with thousands of field-proven units deployed worldwide by every major telecommunications network operator enables easy migration to new network technologies while continuing to reduce expenses. Fast and precise fault location Fast detection Precise fault location One button automation No specific setting required Distance, loss, and ORL measurements Ideal for construction and maintenance Fully automatic or manual modes Templates for multi fiber acquisitions Automatic, semi-automatic, or manual measurments Multitrace display for trace comparison Auto filenaming and auto storage with comprehensive cable and fiber identification Macrobend detection Specifications Typical specifications at 25°C Optical interfaces Applicable fiber SMF 9/125 ?m Interchangeable optical connectors FC, SC, DIN, ST, LC Physical Weight 600g (1.1lbs) Size 213 x 124 x 32 mm (8.38 x 4.88 x 1.26 in) OTDR Optical performance Central wavelength 1310/1550 nm ±20 nm Laser safety class (21 CFR) Class 1M Pulsewidth 10 ns to 10?s ns Distance range Up to 200 km RMS Dynamic Range 32dB / 30dB Event dead zone 2m Attenuation dead zone 8m Technical characteristics Distance units Kilometers, feet, and miles Group index range 1.30000 to 1.70000 in 0.00001 steps Number of data points Up to 128,000 data points Distance measurement Automatic or dual cursor Display span 2.6 m to 200 km Cursor resolution 1 cm Sampling resolution 4 cm Accuracy ±1 m ±sampling resolution ±1.10-5 x distance (Excluding group index uncertainties) Attenuation measurement Automatic, manual, 2-point, 5-point, and LSA Display span 1.25 dB to 55 dB Display resolution 0.001 dB Cursor resolution 0.001 dB Linearity ±0.03 dB/dB Threshold 0.01 to 5.99 dB in 0.01 dB steps Reflectance/ORL measurements Automatic or manual Uncertainty +/-2dB Display resolution 0.01 dB Threshold -11 dB to -99 dB in 1 dB steps Storage Bellcore/Telcordia compatible Version1.1 and Version 2.0 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your auctions on autopilot with Kyozou eBay Auction Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Model	T-BERD 6000
Manufacturer	JDSU
