Johnford Super Turning 4-axis Cnc Lathe With Sub Spindle

US $363,995.00

  • Watertown, Connecticut, United States
  • Jan 30th
Open on mobile:
QR code
Item# 4044 - Johnford Super Turning 4-Axis CNC Lathe with Sub Spindle Machine Specifications: Date of Mfg. 06/2006 Swing over Bed: 28.7” Swing over Cross slide: 23.6” Distance between Centers: 59”   Main Spindle: • Chuck Size: 24” • Bar Capacity: 5” • Spindle Nose: A2-11 • Spindle Bore: 5.2” • Spindle Speed Step: Auto Hi/Lo • Spindle Speed Range: 1500 RPM • Spindle Motor: 22/26 kW • Spindle Bearing Diameters: 7”   Sub-Spindle: • Chuck Size: 24” • Bar Capacity: 3.7” • Spindle Nose: TBA • Spindle Bore: 4.5” • Spindle Speed Step: Auto Hi/Lo • Spindle Speed Range: 1500 RPM • Spindle Motor: 11/15 kW • Spindle Bearing Diameter: 6.3”   12 Tools   Cross Travel X1/X2-axis: 12.6” Longitudinal travel Z1/Z2-axis: 59” Servo Motor X1/X2-axis kW: 4 Servo Motor Z1/Z2-axis kW: 4 Servo Motor W-axis kW: 4   Bed Inclination: 45 degrees Weight: 44,440 lbs. Dimensions: 136.6” Wide X 111.8” High X 220.5” long Power Consumption: 230v 60Hz 3 phase, 150 KVA 400 amp   Standard Accessories: • Fanuc 18i-TB Control (2-path controller) • Coolant System • Splash Guard • Through Hole 3-jaw Chuck • Programmable Hydraulic Tailstock • Chain Type Chip Conveyor • Tool Box and various manuals • Tool holders (direct mounting type) • Auto lubrication with alarm • Halogen working lamp • Rotary Tailstock (4th Axis Series)   Shipping Point: TX Price: $363,995.00 SPECIFICATIONS SUBJECT TO VERIFICATION** Rigging and Hauling NOT Included Call On Target with all your equipment questions-203-441-4655 kevinb@ontargetmachines.com
