Jyetech Jye Tech 06804k Digital Lcd Oscilloscope Diy Kit With 2-inch Lcd, 20mhz

US $706

USA, United States
Jun 2nd

Open on mobile:
QR code

JYETech JYE Tech 06804K Digital LCD Oscilloscope DIY KIT with 2-inch LCD, 20MHz probe JYE Tech Item Description JYE Tech 068 Digital LCD Oscilloscope DIY KIT NEWEST version 06804K not just a kit for training but also a practical tool for everyday use. Operations are even easier thanks to silicone pushbuttons and rotary encoder. Parameter setting is simply, straightforward, and quick. Mode switch and utilities are driven by menu. Absolutely no complicate navigation. This kit is particularly suitable for educational use. It is a great tool for college students. Soldering and assembly required. Battery is not included in standard product configuration and need to purchase separately Features It was designed on the base of DSO 062 kit and comprises many enhancements in hardware and firmware. Major improvements include: Higher sensitivity (10mV/div vs 100mV/div) Wider analog bandwidth (3MHz vs 1MHz) Larger capture buffer (1024 points vs 256 points) Variable trigger position (1% - 100%) with indicator Test signal generator with variable frequency and amplitude USB connection Upload of captured raw data as CSV file Work as USB scope (with jyeLab) and data logger (8 channels, 10-bit resolution) Higher sensitivity (0.2Vpp vs 3Vpp) in built-in frequecy meter Battery/USB powered (Battery not included. USB Cable not included) Fully enclosures Operations of DSO 068 are even easier thanks to silicone pushbuttons and rotary encoder. Parameter setting is simply, straightforward, and quick. Major Part: 1. Main circuit board with pre-soldered ICs and a few SMD parts. Board is pre-tested and MCUs on board are pre-programmed. 2. 128 X 64 graphic dot-matrix LCD module. 3. Step-up voltage converter board (JYE116). It boosts battery voltage to 5V from as low as 2V. 4. Voltage inverter board (JYE120). It generates -5V form +5V with current capacity up to 200mA. 5.On/Off switch board (JYE117). This is the power switch of instrument. [optional] 6. Li-ion battery charger board (JYE118). It includes the USB/Battery power switch circuit. [optional] 7. USB-Uart converter board (JYE119). This bridges the scope to USB host. [optional] 8. Professional 20MHz probe with selectable 1X/10X attenuation. 9.All through-hole components, mechanical parts, and accessaries. 10.Dimension: 140mm X 70mm X 30mm Weight: 120 gram Additional Information Manufacturer: JYE Tech Shipping Weight: 70 Product Dimensions: Width: 4.90 Length: 6.90 Height: 1.90 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
