Kaowool Thermal Insulation Board "m" Grade 12" X 6" X 1/4" Thick Item No. 309

US $37

  • Baldwinsville, New York, United States
  • Jun 15th
  KAOWOOL THERMAL INSULATION  BOARD "M" GRADE  12" x 6" x 1/4" THICK   No.:309 You are buying on One Piece of Kaowool Thermal Insulation Board. It is "M" Grade Board. It measures 12" x 6" x 1/4" thick. Be sure to view all photos as they are an integral component of the item description. Kaowool "M" Series Board has a Maximum Temperature Raring of 2300 degrees F (1260 degrees C). It has High tensile strength at 200 - 300 PSI. High-performance, board, paper and felt products from Thermal Ceramics are the preferred choice over traditional fiberglass, textile, or metal products for thermal, acoustical, or filtration management. Kaowool  "M" Grade Board products are produced from Kaowool high purity fibers and organic binders in a unique paper/felt making process. Each of these paper products are noted for their excellent tensile strengths and outstanding handling characteristics. The "M" Grade Board is manufactured from cleaned Kaowool high purity ceramic fibers resulting in a premium paper product with low shot (unfiberized material) content. The organic binding starch which hold the board together during the forming process burns out and exhibit the smell of burning paper upon the first firings and turns brown. Do not be alarmed. The binders can be "pre-burned" out at 800 degrees C. To achieve the white color it had when received. Kaowool  "M" Grade Board is useful for • Low thermal conductivity and heat storage • Thin, flexible high temperature insulation • Easily die-cut to form complex shapes for high temperature gasketing • Excellent backup and expansion joint material Applications • High temperature gaskets and seals • Refractory back-up insulation • Appliance insulation • Separating media for heat treating metals • High temperature filtration • High temperature expansion joint packing • Glassware separating media • Parting agent for brazing operations • Hot face and backup lining for lab furnaces • Aluminum distributor pan lining • Super alloy ingot mold lining and hot tapes. The specifications for these components are as follows: Length: Approximately 12” (304 mm) Width: Approximately 6” (152 mm) Thickness: Approximately  0.25” (6 mm) Physical Properties: Specific Gravity or Density:   11-13 pounds/ cubic foot (176-208 kg/ cubic meter) Continuous Use Temperature: 2150F (1176C) Maximum Temperature Rating: 2300F (1260C)  Fusion Temperature or Melting Temperature:   1760°C or 3200°F Thermal Conductivity:  @500F (260C) 0.40 BTU inch/hour foot square (0.06 W/m* K)                                           @1000F (538C) 0.63 BTU inch/hour foot square (0.09 W/m* K)                                           @1500F (816C) 0.95 BTU inch/hour foot square (0.14 W/m* K)                                           @2000F (1093C) 1.38 BTU inch/hour foot square (0.20 W/m* K)         Chemical Analysis Alumina: 47% Silica: 53% Loss on Ignition 6-10% from binder burnout Chemical Properties A small amount of organic combustible binder will burn out at approximately 300°F (149°C). Caution should be exercised during the initial heating. Adequate ventilation should be provided to avoid potential flash ignition of the binder out-gassing or avoid air entry while at elevated temperatures.   These components were not specifically manufactured for an individual application; therefore be sure to check the dimensional descriptions carefully for your application. Future returns or requests for refunds, because of some "fit" issue or the like will not be honored. Please check the other Silicon Carbide component variants that are available in my listings for the model or models that best fits your requirement.  Your imagination is the only limiting factor in the spectrum of possible applications for these components and materials.   If you require additional technical information, design, or application engineering consultation, feel free to contact us. As a materials scientist with four decades experience in high temperature processing, ceramics, dentistry, and jewelry manufacture it will be possible to provide you with creative and imaginative approaches to your requirements.    Feel free to ask any questions you may have regarding this item early. Use PayPal only. Combined shipping discount is provided for multiple item purchases. For best results, please be sure to shop using cart, then complete the paying transaction when you are satisfied that all the items you need are in the cart. Items purchased separately will be shipped separately as a unique transaction. Please complete payment transactions within 3 days. Items are generally shipped via USPS first class mail with delivery confirmation.  Ask about shipping costs to your country.   Feedback is provided for all buyers. We will appreciate yours as well.  We strive to maintain excellent customer service; and are able to solve virtually any issues you may have. Every effort to provide the most accurate information about this item and every appropriate precaution in packaging this item is made, to assure that your highest expectations and satisfaction are met, and are exercised to meet this requirement for excellence. In winning this auction or purchasing this item you are agreeing that you will first provide the seller every opportunity to provide redress or resolution to any issues you many have concerning this item, prior to leaving any negative feedback about the seller or the item.    No.:309
