Keysight (agilent / Hp) 81110a Pulse Pattern Generator, 165 Mhz Or 330 Mhz

US $2,210.00

Oceanside, California, United States
Jun 9th

Open on mobile:
QR code

AGILENT 81110A PULSE GENERATOR *Call (760) 806-6600 to RENT this item* DESCRIPTION When the Keysight 81110A (Agilent) Pulse Pattern Generator Mainframe is combined with one or two Keysight 81111A (Agilent) output modules it becomes a single/dual-channel, 165 MHz Pulse Pattern Generator. When the Agilent 81110A Mainframe is combined with one or two Keysight 81112A (Agilent) output modules it becomes a single/dual-channel, 330 MHz Pulse Pattern Generator.(Keysight 81111A and 81112A output channels cannot be combined together into the very same Keysight 81110A (Agilent) Mainframe.) The Keysight 81110A (Agilent) Pulse Pattern Generator produces all the standard pulses and digital patterns needed to test current logic technologies. By using the internal channel addition feature provided by the optional second channel, multi-level and multi-timing signals can be produced. It provides high quality signals and flexibility that meet virtually all application needs. Features and Specifications of the Keysight 81110A (Agilent) Pulse Pattern Generator include: Features: Single / dual-channel pulse pattern generator mainframe Triggerable / PLL operation selectable Synchronously triggerable Variable pulse parameters in both pattern and pulse modes Simulation of reflections / distortions Three / four-level codes Flexible pulses or patterns for Digital Designs: Pattern mode from 80 MHz to 660 MHz, including pseudo-random binary sequence The outputs of dual-channel instruments can be added Upward compatibility Individual solutions for frequencies up to 50, 80, 165, 330, 400 and 660 MHz 100% from/fit compatibility Self-calibration for improved timing accuracy Choice of output modules BNC outputs: 81111A: single-ended 81112A: differential Glitch free change of timing parameters (delay, frequency, transition time, width, delay cycle) Programming language compatible with Keysight 81101A (Agilent), Keysight 81104A, and Keysight 81150A Clean, accurate pulses with excellent repeatability providing reliable measurements Features such as the clear graphical display, autoset, help, store/recall, preset TTL / ECL levels, selectable units (such as current / voltage, width / duty-cycle), and load compensation ensure a high level of convenience that make it easy to use Specifications: Mainframe: 81110A Channel Model: 81111A 81112A Number of Channels: 81111A: 1 or 2 81112A: 1 or 2 Frequency Range: 81111A: 1 MHz - 165 MHz 81112A: 1 MHz - 330 MHz Variable delay range: 81111A: 6.06 ns - 999.5 s 81112A: 1.515 - 999.5 Period RMS - jitter: 81111A: 0.00 ns - 999.5 s 81112A: 0.00 ns - 999.5 s Width Range: 81111A: 3.03 ns - 999.5 s 81112A: 1.515 ns - 999.5 s Amplitude Range: 81111A: 100 mV - 20.0 V (Depends on selected impedance (all other values for 50 ? source impedance into 50 ? load)) 81112A: 100 mV to 3.8 V Transition Time Range (10 / 90): 81111A: 2.00 ns - 200 ms 81112A: 800 ps or 1.6 ns - selectable Source Impedance: 81111A: 50 ? or 1 k? 81112A: 50 ? Configuration Notes: Standard Configuration *All of our equipment has been tested. Additional Calibration may be available upon request! ~Items sold with shown accessories, a power cord and manual on CD (when available)~ WARRANTY, PAYMENT, AND SHIPPING TERMS Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. And although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. All orders also come with a limited 5-day ROR (Right of Return). This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or an item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer, equipment that has been misused or damaged by customer's misuse (intentional or unintentional), or any orders damaged in transit. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your ownshipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.

“Equipment has been tested and is fully functional with a 30-day Warranty!”

Brand	Keysight
MPN	81110A
Model	81110A
Country/Region of Manufacture	Germany
