Keysight/agilent/hp 8114a Opt 001 Baseline High Power Pulse Generator 100v,2a

US $12,250.00

  • Laguna Hills, California, United States
  • Jun 9th
Open on mobile:
QR code
          Keysight/HP’Agilent 8114A Programmable Pulse Generator, 15MHz option 001 The Agilent 8114A 100V / 2A Pulse Generator is a high power, single output source that delivers fast, clean, positive or negative pulses at frequencies up to 15 MHz. ·                 Fast, clean positive or negative pulses up to 100 V at frequencies up to 15 MHz ·                 User-definable limits for voltage, current and duty cycle ·                 TLL input: allows the output to be enabled or disabled ·                 Transitions < 12 ns for high impendance source into 50 Ohm load. Baseline OV. ·                 In 50 Ohm/50 Ohm mode, the maximum voltage is 50 Vpp with transitions < 7ns ·                 Single-channel high power pulse generator ·                 50 Vpp 50 O / 50 O ·                 Maximum amplitude 100 V (HI-Z/50 O) ·                 Maximum current 2 A (HI-Z/50 O) ·                 Voltage, current, and duty cycle protection ·                 Optional baseline shift of +/- 25 V  . Configured with the option 001, Variable Baseline ± 25V     Tested, Guaranteed to work. Sold as pictures, no manuals or additional accessories provided.   CA residents add 8% CA State Sales Tax.
“Few minor scuff on the case, see pictures for details.”
Brand Agilent
MPN 8114A-001
Model 8114A
Country/Region of Manufacture Germany
