Kurt Vise Jaws 1" X 3" X 6"sine Angle Jaws-original Design-5 Min. S/u

US $189.99

Ontario, California, United States
Jan 30th

Open on mobile:
QR code

Note:The first two photos showing the moving jaws are not correct. The moving jaw that comes with this set does not have the 4 vertical "T" slots shown. ************************************** Original Price Of This Angle Jaw Set Was $329-Until The New Configuration Of The Angle Jaw Set Was Designed Price Now Is $189.99 Until Inventory Is Depleted-Very Few Sets Left Clearance Price Is 42% Off Original Price THIS AUCTION IS FOR MY ORIGINAL ANGLE JAW SET, I AM CLEARING OUT MY INVENTORY AT 42% OF THE ORIGINAL SELLING PRICE. THE CLEARANCE PRICE IS LESS THAN MY MFG COSTS. YOUR GAIN MY LOSE, I WANT TO CLEAR THESE SETS OUT SO I CAN CONCENTRATE ON MARKETING THE LATEST VERSION OF THE VISE ANGLE JAW SET. VERY FEW SETS LEFT. View videos of my new and latest configuration of the angle jaw sets, much more versatile, thanks. "ez-sine-machinist-vise.com" FEATURES OF THE ANGLE JAW SET: (1) Required angle to be machined can be set up in less than 2 minutes (2) Locating components are attached securely to the angle jaw for a secure-reliable set-up. (3) Adaptable to a manual mill or a CNC machining center with a fixed head (4) (A)Eliminates tilting the head on a manual mill and having to tram the head back in square. (B) Having to use angle blocks or machine soft jaws for one partticular angle. (5) The locating components are designed to hold small or large parts to machine req'd angles. (6) The vise jaws are made of 6061 aluminum and hard anodized for durability. All the locating components are made of CRS1018 and black oxided to prevent rusting. Jaw size is 1" X 3 " X 6". Mounting hole pattern is for a 6" Kurt vise or others makes with the same hole pattern. (7) Set is self contained, all hardware required to set up an angle quickly and securely is included in the set. Set comes in a hard plastic case with a foam insert to protect the set when not in use. PHOTO DESCRIPTION Photo #1-The complete set as it comes in the protective plastic case. Photo #2-The complete set with all the components laid out. Photo #3-2 angle jaws, one set at 1 deg. and the second set at 5 deg. Photo #4-2 angle jaws, one set at 41 deg.and the second set at 45 deg. (List of the components of the angle jaw set) A-1 ea-Stationary angle jaw. B-1 ea.-Moving/clamping jaw. C-9 ea- L shaped locating arms. .Photo #2. D-All hardware needed to attach components to angle jaw, including allen wrenchs. (short length provided to prevent over tighting) E-8 height stops to raise the part to the necessary height for machining. Attaches to the locating arms. Height stops are in 1/4" increments from 1/4" to 1 1/4" F-Quick reference chart showing the range of each locating arm to expedite set-up. QUICK EXPLANATION OF THE ANGLE JAW SET-UP 1-There are 9 threaded pivot holes that are located at the bottom edge of the angle jaw which are numbered 1-9. These are the pivot holes that the L shaped locating arms are attached to.. 2-There are 9 sets of threaded c'bored holes (upper half of the angle jaw). Each set has 5 holes ea. Each set are also numbered 1-9. Each set of 5 holes cover a range of 5 deg. 3-Starting from the set that is on the far left side that is numbered #1. This set covers angle 1 deg. to 5 deg.,the next row covers the angle range of 6 deg. to 10 deg. and so on until the very last row on the right #9 covers the angle range of 41 deg. to 45 deg. 4-The top hole on each set is the always the lowest degree of the each set and the bottom is always the highest degree of each set. 5-Each numbered L shaped locating arm also covers a 5 deg. range. Photo #3 shows 2 angle jaw using the shortest locating arm (#1) attached to the pivot hole #1. One arm is attached to the top hole which is 1 deg. and the second locating arm is attached to the bottom hole, setting the angle at 5 deg. 6-Photo #4 illustrates the jaw setting for 41 deg. and the other jaw set at 45 deg. using the (#9) locating arm attached to the #9 pivot hole and the top a #9 set. After setting up the angle jaw a couple times you will be able make a angle set up in a couple minutes. . Purchase must be paid by Paypal. I ship by USPS priority mail 2-3 delivery Purchase with confidence-I have 100% positive feedback

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Kurt
Country of Manufacture	United States
