Lcd Awc708c Lite Co2 Laser Cutting Engraving Machine Motion Controller System

US $399.00

Hong Kong, China
May 10th

Open on mobile:
QR code

DSP LCD AWC708C LITE CO2 Cutting Engraving Machine Motion Laser Controller System product description Item Description: Features: Awc708C Lite----------------New Fresh Version Based On AWC608 And AWC608C! AWC708C LITE is an independent DSP laser controller used for the laser cutting and engraving systems. Technical Specifications: Power Model AWC 708c lite Power supply DC 24V,3A Laser power 0-100%,0.01% continuous adjustment Accuracy ±0.001mm Max Coordinates Defined by customer Laser Source Type Various AC/DC Excitation and RF CO2 laser & Solid medium Application Laser cutting machine, Laser engraving machine, etc Environment Operating temperature: (-10~40)C,Relative humidity: ≤90% Gross Weigh 1.5Kg Certificates CE,ROHS Support OS: Window Win8/Win7/XP/2000/Win7. Support 64bit (driver installed separately) In/Out Interface port: USB or networking Real time power control: PWM and analog Support Dump drive(no PC required) for up to 200 files Cad system support: CorelDraw (v12~X6), Illustrator, and AutoCad (2004 ~ 2008) direct output with VB plugin Advanced features: 4.3” true color TFT screen,more lager then AWC608 series. Can display true color graphics processing on the panel , and accurately informed of the coordinate position of the laser processing head on the panel ; The dynamic display processing tracks and coordinates ; The whole dynamic display graphics processing progress bar ; Using the control panel with USB interface,more convient for human operation. It support up to 4 different axis. It can work together with a PC or read files from U-disk directly and work without PC. User can operate the whole work directly from the display easily. AWC 708 laser controller for making industrial laser systems and DIY laser engraver and DIY laser cutter and upgrading your old laser systems. New features added: Dynamic color LCD screen showing work progress Over-burned compensation PPI control (per layer) Fast X,Y pan control Supports real time X-Y coordinate display Controllable starting point and parking location Cutting & engraving can be done in one shot Multiple layers for speed & power control Multiple pass engraving or cutting per layer Extended guideline for cutting enchantment. Great help for cutting circular objects On-board Bios upgrade Network connection for faster file download USB interface for OS upgrade Hardware limit added for X+ and Y+, total of four limit switches can be installed Driver connection enhancement (3 wires instead 4 or 5 wires) Multiple origin Z axis speed control (on LCD) Intelligent art work arrangements help save materials Graphic job simulation - Job time calculator many more features... Software features: (1) friendly interface, easy, easy operation (2) compatible AI, BMP, PLT, DXF, DST and so on many kinds of image data format (3) can produce simple graphics, characters and the import data editing and publishing (4) multi-stage stratified processing and definition can output order (5) processing and precision personalized Settings, the optical trajectory simulation shows operation (6) many path optimization function in process of suspended function (7) graphics and processing parameters of the preservation method and use again (8) processing time estimate and cost budget function, intelligent typesetting input (9) array output, the designated output immediately, back to the origin of the output localization way (10) unique double laser system work independently work with intermittent movement and path compensation control function (11) According to the different needs of Ø processing could set processing starting point, work, the optical path dock position, etc (12) compatible with a variety of communication, the user can according to actual situation the USB port communication or network communication (13) support CorelDraw direct output version, AutoCAD direct output version (14) perfect without electricity for carving function; Work in real time working condition and main board record optical position, suddenly drop after power and restart the machine can continue to power lost before the unfinished work. (15) this controller support four shaft: X, Y, Z, U. The Z axis is used as a lift, U feeding shaft (16) af, need not adjust to the optical the focal length of the object, very convenient new users. (17) engrave photos, support rotating sculpture, a variety of protection interface, there are two kind of limit way limit software, hardware limit (18) support slope sculpture, support the mainboard online upgrade, support almost all U dish brand all capacity Package Included: 1*AWC708 Controller board with Aluminum case 1*LCD Panel Size: 150mmX100mm 4*Cable -------------------USB cable,USB extended cable,network cable,Panel connection cable 1* A CD including LaserCAD Laser CAD software Important Note: Our goal is to achieve 5-star rating of each transaction. If you are not 100% satisfied,PLEASE don't leave a neutral or negative but contact us by Ebay message or email First so that we can help you. Payment: We ONLY accept paypal We appreciate prompt payment and look forward to your business in the future. Shipping: Item will be shipped within 1-2 working days after full payment is received. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We ship to worldwide by post air mail it will cost about 15-20 business days!( Holliday time may longer cause post office need process more packages) Return Policy: In the unlikely event that a return is request, all returns must include all original items undamaged, in re-saleable condition. Refund request is available within 1 weeK and Exchange request is available in 1 months after parcel received & returning the item as the same condition as received. About Us: Please contact us if the item has not arrived within 30 days for any reason. We reserve the right to refuse the order for all non-registered bidders which is reported from eBay. Please bid ONLY if you agree to the above terms. Your 5-star positive feedback will be highly appreciated.. Please contact us before leaving a negative feedback. We would try our best to help you solve the problem. Please allow us to reply your email within 1-2 Days. If there are any issues with the purchase, please contact us at ebay message or Email, We will reply you ASAP. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	SKU	B090
Model	AWC708C Lite
