Lcr-t4 Esr Meter Transistor Tester Diode Triode Capacitance Nice Inductance W1g7

US $13.49

shanghai, China
Jul 8th

Open on mobile:
QR code

LCR-T4 ESR Meter Transistor Tester Diode Triode Capacitance SCR Inductance NICE Description Description Description&Previewshipping&policyDescription: Product Description Capacitance Diode LCR-T4 M328 Transisor Inductance Tester Triode SCR Meter ESR Features : 1,2013 latest M328 version of the software ,more functions.Chip: Atmega328 2.128*64 big Backlight LCD display,only 2mA when stand by. 3,Using 9V battery (Not included) Test ranges: Inductors, capacitors , diodes, dual diode , mos, transistor, SCR , the regulator, LED tube , ESR, Resistance,Adjustable potentiometer Resistance :0.1 ohm resolution, maximum 50M ohm Capacitor :25pf -100,000 uf Inductors : 0.01mh-20H Function: 1:Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFET, diode (including double diode), thyristor, transistor, resistor and capacitor and other components 2: Automatic test the pin of a component, and display on the LCD 3:Can detect the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage 4: Measure the gate and gate capacitance of the MOSFET threshold voltage 5:Use 12864 liquid crystal display with green backlight Specifications: For you reference 1,One -button operation, automatic shutdown . 2,Only 20nA shutdown current. 3,Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4,Automatic identification components pin arrangement . 5,Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6,Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7,Can detect bipolar transistors and MOS transistors protection diodes. 8,Measuring the gate MOS FET threshold voltage and the gate capacitance. 9,Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10,Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11,Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13,Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15,Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16,Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 18 can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter . Package Included: 1PCS x Mega328 Transistor Tester Diode Triode Capacitance ESR Meter MOS PNP/NPN Preview: Thank you for your purchase Problems? You can follow below process to chontact us. There is a time zone difference,but we will do our best to quickly response to your questions: Shipping - Handling time :48 hours - Standard to USA :about 7-14 working days(ePacket) -Economy to USA:about 20-35 working days(NO tracking under $5) - Economy Int'l Shipping:20-35 working days(NO tracking under $20) -Standard Int'l Shipping:20-35 working days(With tracking) -But like Russia,and some South Ameria country maybe need 2-3 weeks more. Please make sure your address in ebay is correct. we will only follow your address listed in the ebay orders for the shipment. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Payments We accepts Paypal only If you have any questions about the payment,please contact us through eBay message. Import Duties In case some duty is due Upon delivery, it is your responsibility to meet that expense and this may cause delays to delivery schedule and you may have to pickup goods at the customs office. Terms & Conditions By bidding on this item,the Buyer agrees to all of the terms and conditions as outlined in this listing .please ensure to read and agree to All eBay terms and Conditions before bidding. All pictures are for illustration purpose only and Colours may vary slightly. Our store obeys all eBay Rules and Policies. Returns Policy To Return an item you must contact us and take photos of your item to clearly show any damage or unusual aspects of it. Approved returns will be subject to inspection on arrival. Items must be returned in original condition with all original packaging. All shipping and handing charges are non-refundable Return delivery costs are the responsibility of the buyer. We will cover the cost if sending replacement/repaired items. Within 7 days after receiving your products, we offers a no-hassle 7 day exchange/replace only if your items are found to be defective by manufacturer. Payment Shipping Terms of Sale About Me

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Features	Array
Brand	Unbranded
Resistance	0.1 ohm resolution, maximum 50M ohm
MPN	Does Not Apply
Capacitor	25pf -100,000 uf
Country/Region of Manufacture	China
Inductors	0.01mh-20H
Type	as shown
Specifications	For you reference
