Leadshine 3-phase Stepper Set (drive + Motor) 3dm583+863s42 4.2n.m 1.2 Degree

US $254.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 3-phase Stepper Set (Drive + Motor) 3DM583+863S42 4.2N.m 1.2 degree 5.0A New 3DM583 Introductions: The 3DM583 is a versatility fully digital stepping driver based on a DSP with advanced control algorithm. The 3DM683 is the next generation of digital stepping motor controls. It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability. Motor self-test and parameter auto-setup technology offers optimum responses with different motors and easy-to-use. The driven motors can run with much smaller noise, lower heating, smoother movement than most of the drivers in the markets. Its unique features make the 3DM583 an ideal solution for applications that require low-speed smoothness. Compared to the 3ND583, broader input voltage and output current ranges make the 3DM583 can drive much more motors than the 3ND583. Features: *Anti-Resonance, provides optimum torque and nulls mid-range instability *Motor self-test and parameter auto-setup technology, offers optimum responses with different motors *Multi-Stepping allows a low resolution step input to produce a higher microstep output for smooth system performance *Microstep resolutions programmable, from 200 to 102,400 steps/rev *Supply voltage up to +50 VDC *Output current programmable, from 2.1A to 8.3A *Pulse input frequency up to 200 KHz *TTL compatible and optically isolated input *Automatic idle-current reduction *Suitable for 3/6 leads Three-phase motors *Support PUL/DIR and CW/CCW modes *Over-voltage, over-current, phase-error protections Specifications: Model Output current (A) Supply voltage (V) Microstep resolution Weight (kg) Match motors (NEMA size) Size Control signals PUL/DIR; CW/CCW Single-ended; Differential 3DM583 2.1-8.3 DC (18-50) 200-10000s/r 0.38 17, 23, 34 118*75.5*33 PUL/DIR; CW/CCW Single-ended; Differential Applications: Suitable for a wide range of stepping motors, from NEMA frame size 17 to 34. It can be used in various kinds of machines, such as laser cutters, laser markers, high precision X-Y tables, labeling machines, and so on. Its unique features make the 3DM683 an ideal solution for applications that require both low-speed smoothness and high speed performances. Other hot items of this Leadshine stepper drives for above applications: DM422 Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DC18-40V 0.3-2.2A DM422 New DM556 Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DM556 DC18-50V 0.5-5.6A New DM870 Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DM870 DC18-80V 0.5-7.0A New DM805-AI Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DM805-AI DC18-80V 0.5-7.0A New DM1182 Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DM1182 AC80-150V 0.5-8.2A New DM2282 Leadshine 2-phase DSP Based Digital Stepper Drive EM Series DM2282 AC80-220V 0.5-8.2A New 3DM683 Leadshine 3-phase DSP Based Digital Stepper Drive EM Series 3DM683 DC18-60V 0.5-8.3A New 863S42 Introductions: The 863S42 three-phase stepper motor is suitable for a wide range of motion control applications. Terminated with 6 motor leads, the motor can be connected in delta connection Features: *3-phase hybrid step motor *High torque design *Standard NEMA 34 dimensions *Delta wiring *Optimized for microstepping Specifications: General Step Angle 1.2° Step Angle Accuracy +5%(full step, no load) Temperature Rise 80°CMax Ambient Temperature -10°C -- +50°C Insulation Resistance 100M?min.500VDC Dielectric Strength 500VAC for one minute Shaft Radial Play 0.06 Max.(450g-load) Shaft Axial Play 0.08 max.(450g-load) Model No. Step Angle Holding Torque Current /phase Inductance /phase Resistance /phase # of leads Rotor Inertia Detent Torque Motor Weight Motor Length L (°) N.m A mH Ohm g.cm2 N.cm Kg mm 863S22 1.2 2.0 5.0 2.8 0.9 6 1200 - 2.1 73 863S42 1.2 4.0 5.0 4.5 1.35 6 2500 - 3.0 105 863S68H 1.2 6.78 3.5 20 4.5 6 3300 - 3.8 127 Matching drives: Model Match drives 863S22 3DM683/3DM883 863S42 3DM683/3DM883 863S68H 3DM683/3DM883 Applications: Suitable for all kinds of small and medium-sized automation equipment and instruments, such as: engraving machine, marking machine, cutting machine, laser typesetting, plotter and CNC machine tools, automatic assembly equipment, etc. The efficiency is very high for the users who expect low vibration, little noise, high precision and high speed small equipments. Other hot items of this Leadshine 3-phase stepper motors for above applications: 573S05 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S05 Step Angle 1.2 Degrees 5.2A 0.45N.M New 573S09 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S09 Step Angle 1.2 Degrees 3.5A 0.6N.M New 573S15 Leadshine 3-phase Stepper Motor 573S NEMA23 Series 573S15 Step Angle 1.2 Degrees 5.8A 1.3N.M New 863S22 Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S22 Step Angle 1.2 Degrees 5.0A 2.0N.M New 863S42 Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S42 Step Angle 1.2 Degrees 5.0A 4.0N.M New 863S68H Leadshine 3-phase Stepper Motor 863S NEMA34 Series 863S68H Step Angle 1.2 Degrees 3.5A 6.78N.M New Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM Shipment: Once payment received. Item will be shipped out within 1-3 working days by DHL, Fedex, UPS, EMS ASAP. Usually it takes 3-7 working days to most of the country. You will be notified the traking number once shipped out. Kindly please note the Tax fee and Customs clearance fee are not included in the item’s listing price. Kindly please feel free to contact us before shipping if there’s any thing we can do for you. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: We accept return or refund within 14 days for the quality reason, not man-made reason. Kindly please contact us before returning the package. Payment will be refunded to you within 24hrs once the package received by us. You understanding appreciate. Kindly note: Pls check and confirm the part NO. and your application before place order, any further assistance please feel free to let us know. Company picture:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	3DM583+863S42
Model	3DM583+863S42
