Lecroy Waveace 101 Digital Oscilloscope - Used Only Few Times...

US $499.00

Ann Arbor, Michigan, United States
Jan 29th

Open on mobile:
QR code

WaveAce 101 Digital Oscilloscope Bought this oscilloscope few years ago for a project that I was working on. Used it barely few times. It is in excellent working and cosmetic condition. Comes with all the original probes, cables manuals and CD with the software. Two original probes are brand new and have never been used. PayPal only. Will ship to confirmed addresses only in US. Vertical System Rise time 8.8 ns Bandwidth 40 MHz Input Channels 2 Bandwidth Limiters 20 MHz Input Impedance 1 M? ± 2% || 17 pF ± 3 pF Input Coupling AC, DC, GND Maximum Input Voltage ± 400 Vpk Channel-Channel Isolation >= 100:1 at 20 MHz Vertical Resolution 8 bits Sensitivity 2 mV/div - 5 V/div DC Gain Accuracy ±3%: 5 mV/div - 5 V/div (fixed gain ranges) ±4%: 2mV/div and variable gain ranges Offset Range ±2 V: 2mV/div - 100 mV/div ±40V: 102 mV/div - 5 V/div Horizontal System Time/Division Range 10 ns/div - 50 s/div Clock Accuracy 100 ppm Trigger and Interpolator Jitter 2 ns (pk-pk) Acquisition System Single-Shot Sample Rate/Ch 500 MS/s on 1 Ch 250 MS/s on 2 Ch Equivalent Sample Rate 25 GS/s Memory 4 kpts/ch Acquisition Modes Averaging Selectable Number of Sweeps: 4, 16, 32, 64, 128, 256 Peak Detect 10 ns Interpolation Linear, Sin x/x Enhanced Resolution na Sequence Mode na Triggering System Modes Normal, Auto, Single, Stop Sources Ch 1 - Ch 2, EXT, EXT/5, AC Line Coupling Mode AC, DC, LF Rej, HF Rej, Pre-trigger Delay memory/(2 * sample rate) Post-trigger Delay 260 Divisions Hold-off by Time or Events 100 ns - 1.5 s Internal Trigger Range ±6 divisions from center Trigger Sensitivity 1 division: DC - 10 MHz 1.5 divisions: 10 MHz - 40 MHz External Trigger Sensitivity Ext: 200 mVpp from DC to 10 MHz 300 mVpp from 10 MHz to 40 MHz Ext/5: 1Vpp from DC to 10 MHz 1.5 mVpp from 10 MHz to 40 MHz External Trigger Input Range Ext: ±1.2 V, EXT/5: ±6 V Display Type Color 5.7" TFT-LCD Resolution QVGA; 320 x 234 pixels Grid Styles YT (12 horizontal divisions), XY Trigger Types Optional Advanced Triggers na Optional Serial Data Triggers na Internal Storage Waveform Storage 20 waveforms and 2 reference waveforms Setup Storage 20 setups Math Number of Math Traces 1 Standard Math Functions Add, Subtract, Multiply, Divide, FFT Optional Math Functions na Measurements Number of Measurements Displayed 5 Measurement Parameters Amplitude, Average, Base, Burst Width, Cyclical RMS, +Duty Cycle, -Duty Cycle, Fall Time, Frequency, Max, Mean, Min, Overshoot, Peak-Peak, Period, Phase, Rise Time, RMS, Top, +Width, -Width, First Rising-Rising, First Rising-Falling, First Falling-Rising, First Falling-Falling, Last Rising-Rising, Last Rising-Falling, Last Falling-Rising, Last Falling-Falling Interface GPIB Port (optional) na USB (Device) 1 Ethernet Port na USB (Host) 1 Serial Port 1 Probes Probes Qty. (2) ?10/1 Passive Probes Scale Factors Manual: ?1, ?10, ?100, ?1000 Calibration Output 1 kHz square wave, 3Vp-p (typical), output to probe hook Power Requirements Voltage 100 - 240 VAC, 45 Hz to 440 Hz Max. Power Consumption 50 VA Environmental and Safety Temperature (Operating) 10 °C to 40 °C Temperature (Non-Operating) -20 °C to 60 °C Humidity (Operating) 85% RH, 40 °C Humidity (Non-Operating) 85% RH, 65 °C Altitude (Operating) 3000 m Altitude (Non-Operating) 15,266 m Physical Dimensions Dimensions (HWD) 154 mm x 305 mm x 133 mm (6" x 12" x 5.25") Weight 2.3 kg (5 lbs)

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Used only few times. Excellent working and cosmetic condition.”
