Logic Analyzer & Data Logger-PLA-2532, US $2000 – Picture 0
Logic Analyzer & Data Logger-PLA-2532, US $2000 – Picture 0

Logic Analyzer & Data Logger-pla-2532

US $2000

  • Tokyo, default, Japan
  • Jan 29th
Open on mobile:
QR code
The PLA series provides complete date acquisition system, Logic Analyzer and Data Logger. This small instrument is making digital software and hardware designers the ability to quickly capture thecomplex signals for analysis and debugging. Moreover, the PLA is able to cooperate with your own design program for test automation system. Logic Anaryzer ? Internal (asynchronous) and External (synchronous) capture:Offer a more convenient environment for engineers. ? The timing of each trigger point can be shown by the cursor mark. ? Binary code and hexadecimal List mode (State) display. ? Able to save measuring data and waveform results. ? Provide various signal trigger and capture:Pattern/Edge/AND/OR, 4 kinds of trigger modes. ? Provide various signal trigger and capture:Total of four kinds of trigger modes including Pattern/Edge/AND/OR. ? 256K Bytes ~ 2M Bytes long memory depth;each CH memory depth is up to 128Kbits ~ 512Kbits. ? The adjustable sample rate size can be set by users, which avoids long capturing time. ? “Trigger Counter” and “Pulse Width Trigger” function. ? High-speed Zoom In/Zoom Out function. ? Smart software provides text file for saving the Binary Code of waveform. ? USB 2.0 interface for PC link function, which can connect with PC for user to save, analyze, view and printout. ? Powered by USB. Data Logger ? Provide friendly software, no matter what program language, just key in the timing,  trigger condition and logic level etc, then  start the data acquisition. ? Use binary for logging the code. Specification PLA-2532(New) * Timing Analysis : 250MHz,max(4ns) * State Analysis : 100MHz(Max) * Bandwidth : 100MHz * RAM Size : 2M Bytes * Storage Depth Per Channel : 512Kbits x 32CH * Glitch Capture : Yes * PC-Link Interface : USB 2.0 PC System Requirement Operating System Windows 98/2000/XP/Vista32
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Leaptronix
MPN PLA-2532
Model PLA-2532
Country/Region of Manufacture Taiwan
