M335 Cnc Stepper Driver Board For Mini Milling/router Machine Nema16 17 23 Motor

US $28.59

Los Angeles, United States
Jun 9th

Open on mobile:
QR code

{{{TBR_DOMAIN_NAME}}} eBay Item M335 CNC Stepper Driver Board For Mini Milling/router Machine Nema16 17 23 Motor SAVEBASE is a customer satisfaction oriented online business company supplying you with the best valued and affordable accessories and parallel devices for your personal digital equipments.Enjoy peace of mind shopping experience with us. © SAVEBASE.com All Rights Reserved Only USD +P&P USD* More.. Product Info Jump to :: Specifications :: What's in the Box M335 High Performance and Low Cost Microstepping Driver Descriptions The M335 is a high performance microstepping driver with low price. The M335 adopts single-chip PWM bipolar sinusoidal chopper to ensure the low vibration and high efficiency. It is suitable for driving 2-phase and 4-phase hybrid stepping motors, so the Nema16-Nema23 stepper motors with a 0.5A-3.5A current will be suitable. If you are looking for a device with low cost and stable function, this is an excellent choice for you. Click here for the specification of M335 Features M335 Microstepping Driver Low cost, Non-creeping phenomenon under low speed. Low noise and non-resonant region. 1, 2, 8, 16 adjustable micro step control for more accurate and smoother motor running. Remain output torque with higher micro step. Supply voltage up to 30V DC. Output current up to 3.5A. Suitable for 2-phase and 4-phase motors. High speed optoelectronic isolation signal input. Single-chip PWM bipolar sinusoidal chopper ensures low vibration and high efficiency. Automatic idle-current reduction. Protection of power reversal. Applications Suitable for a variety of small sized automation equipment and instruments, such as: engraving machine, marking machine, cutting machine, laser typesetting, plotters, CNC machine tools, handling the devices. Suitable for a wide range of stepping motors, from NEMA size 16/17/23. Power Supply Selection Voltage Selection 12-24V DC power supply for Nema 16/17 stepper motors. 24-30V DC power supply for Nema 23 stepper motors. (High (≥ 30V) voltage will burn out the chips or stepper motors!!! Please be careful in choosing power supply.) Current Selection Output current of the power supply can be calculated by the following formula Output current = Rated current of your stepper motors x quantity + 2A Please SHUT DOWN the power before you plug or unplug the connectors to avoid burning up the board. M335 DIP-Switch Settings Microstep Resolution Setting Microstep resolution SW1 SW2 1 OFF OFF 1/2 ON OFF 1/8 ON OFF 1/16 ON ON Decay Mode Setting Decay Mode SW5 SW6 No Decay OFF OFF Slow Decay ON OFF Medium Speed Decay OFF ON Fast Decay ON ON Output Current Setting SW3 SW4 Full Current Auto Half Current Peak Current RMS Peak Current RMS OFF OFF 3A 2.14A 1.5A 1.07A ON OFF 2.25A 1.6A 0.6A 0.42A OFF ON 1.5A 1.07A 1.5A 1.07A ON ON 0.6A 0.42A 0.6A 0.42A M335 Interface Instruction Function Instructions Function Details Microstep Resolution Setting Microstep resolution is set by SW1, 2 of the DIP switch .Users should first stop drivers working when adjusting the microstep resolution. Dynamic Current Setting Dynamic output current is set by SW3, 4 of the DIP switch . Decay Mode Setting With the decay mode from 0% to 100%, the attenuation increases. Users can eliminate the stepper motor locked noise and improve motion stabilization by switch SW5, SW6. Automatic Half-current Function Output current is automatically switched to 50% after signal pulse stop for about 0.4 seconds (according to the table settings). This can make the motor and drive heating reduction, improved reliability. Theoretically 25% reduction in the heat (heat is proportional to the square of the current). Signal Interface PUL + and PUL - are the positive and negative terminals to control the pulse signal. DIR + and DIR - are the positive and negative terminals of direction signals. ENA + and ENA - are the positive and negative terminals of enable signals. Stepper Motor Interface A+ and A- connect with the positive and negative terminal of A phase winding. B+ and B- connect with the positive and negative terminal of B phase winding. You can reverse the motor direction by swapping A, B phase windings. Supply Voltage Interface DC Power Supply: 12-30V DC.Recommend voltage:24V LED Indicators Driver has green led indicators. The green led indicator light on when the driver get power. Installation The dimension of the driver is 97 x 75 x 35mm . It is recommended to mount the driver vertically to maximize heat sink area. Connection Diagram for Reference Specifications Electrical Specifications Of M335 Microstepper Driver Input Voltage 12V ~ 30V(Peak) DC Output Current 0.5A ~ 3.5A (Peak) Drive Type Pulse + Direction + Enable Signal Control (Single-Chip PWM Bipolar Sine Chopper) Suitable Motor Nema16, Nema17, Nema23 Isolation Resistance 500MΩ Dimensions 97*75*35mm Operationg Environment & Other Specifications Of M335 Microstepper Driver Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0 °C ~ 50°C (32°F ~ 122°F) Humidity 40%RH ~ 90%RH Operating Temperature 70°C (158°F) Max Storage Temperature -20 °C ~ 125°C (-4°F ~ 257°F) Total Weight Approx. 200g Mechanical Specification(unit:mm) What's In 1x M335 Microstepping Driver 1 x CD Driver Click here for the Mach3 software Estimated Delivery Time USA (excl. Alaska, Hawaii, Puerto Rico) USPS First-Class Package/UPS Ground/USPS Priority 3-7 business days Other Countries or Regions(May depart from other stock location) Airmail Service 12-21 business days Remarks: *Your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notifications will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *All parcels will be shipped by small packet, it is not guaranteed that parcel should arrive within the time stated above. However, 95% parcels will be delivered within the reference time. * PayPal: We accept PayPal ONLY (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) Remarks: *Please send payment within 5 days after auction ended. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer one year warranty on all products purchased from us. If your item has any warranty issue please contact us for a satisfying solution. Remarks: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are not refundable. Agreement: By placing an order, you acknowledge that you have accepted the terms and conditions of sale.You are welcome to contact us with any questions.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NBNC
UPC	190080043520
MPN	100435201
