Tb6560 Cnc Stepper Motor Driver Board Controller 3 Axis

US $55.69

Los Angeles, United States
Jun 9th

Open on mobile:
QR code

TB6560 CNC Stepper Motor Driver Board Controller 3 Axis More.. *NEW* 3 Axis TB6560AHQ Stepper Motor Driver Controller Product Features: Toshiba TB6560AHQ chip - High power, maximum 3.5A drive current chipset ! For TB6560AHQ Datasheet, Please click here. 1-1/16 microstep setting - Higher accuracy and smoother operation than standard 1, 1/2 step Adjustable 1.5A-3A drive current settings for each axis - 25%,50%,75%,100% of full current can be set for different stepper motors *Attention: This driver is 1.5A-3A version, which is specially designed for stepper motors with rated current from 1.5A to 3A. It's NOT compatible with stepper motors with rated current below 1.5A or above 3A. Overload, over-current and over-temperature safety - Full protection for your computer and peripheral equipment. On board current switching - Power output can be set according to specific user requirement. Full closed-type optical isolation to protect the user's computer and equipment. Relay spindle interface - Outputs Max. 36V 7.5A for spindle motors or coolant pump (only one device can be powered by this output!) 4 channel inputs interface- Can be used for XYZ limit and emergency stop. Professional design - Two stage signal processing with super anti-jamming. Bipolar constant current chopper drive with non-resonant region - Controls motors smoothly through range without creep effect. Four-input Control; Allow setting the Limit, Emergence-Stop, Midpoint-Alignment, Cutter-Alignment. Universal architecture - Supports most parallel software MACH3,KCAM4 etc. *For compatibility with other softwares, please feel free to contact us. Dip settings: Current Setting 1 2 Decay Mode Settings 3 4 MicroStep Settings 5 6 100% ON ON FAST ON ON 1 ON ON 75% ON OFF 25% ON OFF 1/2 ON OFF 50% OFF ON 50% OFF ON 1/8 OFF ON 25% OFF OFF SLOW OFF OFF 1/16 OFF OFF Further Details: Power supply DC 12-30V (not included, please feel free to contact us if you need !) *The stepper motor directly gets the power from the stepper driver, it doesn't require a separate power source.. *Voltage Selection: 12-16V DC power supply for Nema 17 stepper motors 16-24V DC power supply for Nema 23 stepper motors (High voltage will burn up the chips or stepper motors!!!) *Ampertage Selection: Output current of the power supply can be calculated by the following expressions: Output current = Rated current of your stepper motors * quantity + 2A (For example, if you want to drive 3 * 3A Nema 23 stepper motors, theoretically 24V 11A DC power supply is recommended, but higher power such as 24V 15A also will be good. If you are not sure about the selection of power supply, please feel free to contact us for help) The power output of 12V shall be applied to the radiator fan of 12V Driver output compatible with 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max. Suitable for unipolar or bipolar stepper motors. Voltage regulated spindle speed controlled by parallel interface as function of supply voltage. *NOTE: Please SHUT DOWN the power before you plug or unplug the connectors to avoid burning up the board. Connection Diagram: *NOTE: These external tools on the left and bottom of the following picture are only for exhibition. We don't have them for sale at the moment! Electrical properties (ambient temperature Tj = 25 °C pm): Input Power 12-30V DC power supply Stepper motor drive current 1.5A - 3A/phase Drive type Double-pole constant flow PWM actuation output Compatible Stepper motors 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max. Dimensions 18 * 14 * 4 cm (L*W*H) 1 x 3 Axis TB6560 Stepper Motor Driver 1.5A-3A 5 x Wire connectors 1 x White ribbon 5-pin limited cable 1 x DB25 parallel cable 1 x CD Driver For the MACH3 Sofeware, Please click here For the English User Manual, Please click here Shipping Payment Warranty Estimated Delivery Time USA (excl. Alaska, Hawaii, Puerto Rico) USPS First-Class Package/UPS Ground/USPS Priority 3-7 business days Other Countries (May depart from other stock location) International Airmail Service 10-20 business days Please DO CONTACT AND CONFIRM with us BEFORE you bid IF you: - need the item urgently. - require that the item should be delivered within a certain time. - have any other questions/requirements about delivery. Remarks: *Usually, your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notification will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *It is not guaranteed that parcel should arrive within the time stated above. However, 95%+ parcels will be delivered within the reference time. *Please contact us if you have any trouble in receiving your orders. We will help you to track them. PayPal: We accept PayPal (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) * If you have difficulty to make payment by PalPal please contact us for alternative payment method. Remarks: *Please send payment within 5 days after auction ends. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure that your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer ONE YEAR warranty on this product. If your item has any warranty issue please contact us for a satisfying solution. Requirements: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are on customers cost and not refundable.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HY
UPC	190080014889
MPN	100148801
