Marathon Electric Motor 5kh32en5015u 4785 Hp 1/4 Volts 115 Rpm 3450

US $200

  • Fairbanks, Alaska, United States
  • Jun 11th
4785, 5KH32EN5015U, 1/4 Hp, 115, Split Ph. And Capacitor Start, 48N FR., 3450 Rpm, Open, NEMA Flange Mount, Oil Burner, Manual over load. 60 Hertz HP 1/4 Voltage 115 kW - FL Amp 4.1 RPM 3450 FL Eff 0 % SF 1 Phase 1 Insulation Class B Frame 48N Duty Continuous Enclosure TENV Ambient 40 Mounting N/R NEMA Design Orientation Horizontal or Vertical Starting Type Switch and Mech Assembly - KVA Code P Drive End Bearing SLEEVE IP Code Opposite End Bearing SLEEVE Drive End Bearing Size .500 Rotation Clockwise Opposite End Bearing Size .500 Hazardous Location N/R Weight 12 LB CE - CSA - UL Y Thermal Protection Manual PRODUCT SPECIFICATIONS BRANDMarathon Motors MOUNTINGFlange Mount MOTOR RPM 60Hz3450 @ 60 Hz DUTYContinuous FRAME48N VOLTS115 @ 60 Hz HORSEPOWER1/4 @ 60 Hz AMBIENT TEMP C40 WEIGHT LBS13 ULY ROTATIONClockwise CATALOG NO.4785 STARTING TYPESwitch and Mech THERMAL PROTECTIONManual KVA-CODEP OPPOSITE END BEARINGSleeve RPM3450 @ 60 Hz SERVICE FACTOR1 @ 60 Hz PHASE1 ENCLOSURETENV BEARING-DRIVE-ENDSleeve INSULATION CLASSB OPPOSITE END BEARING SIZE0.5 DRIVE END BEARING SIZE0.5 MODEL NUMBER5KH32EN5015U 60 HERTZ FL AMPS4.1 ORIENTATIONHorizontal or Vertical
