Materials Development Corp. Mdc 8512 Duo Chuck Hot Chuck System, 4-mo. Warranty

US $12000

Palisades Park, New Jersey, United States
Jun 2nd

Open on mobile:
QR code

Please contact us for additional information through ebay mail, or directly at: nrscientific@gmail.com (201) 592-1864. Materials Development Corp. MDC Model 8512 Duo Chuck Integrated Hot Chuck System with 4-mo. Warranty Model: 8512 S/N: 150 117 V / 50-60 Hz / 10 A. External Dimensions: 21.5"w x 20"d x 9"h This duo chuck wafer system is in excellent cosmetic and perfect operational condition, and carries our standard 4-month, no-nonsense warranty. For your reference, the seller is N&R Scientific Co., Inc. We have been providing the highest quality refurbished and fully guaranteed equipment worldwide for many years. You can purchase with complete confidence that the equipment will be provided in excellent cosmetic and perfect operational condition. Our facility is located in the metropolitan NYC area. Please note: for purchases of this size, we are unable to accept credit cards or PayPal unless special arrangements are made. Kindly contact us regarding suitable payment arrangements. Manufacturer's Description: The MDC Model 8512 DuoChuck Integrated Hot Chuck System is the first hot chuck system designed by a C-V plotter company for use exclusively with computerized C-V plotters. Several unique features of this hot chuck system enable faster and more efficient mobile ion measurements than have been previously possible. In one dark box enclosure, the MDC DuoChuck combines two independent hot chucks, all temperature controller and stress supply electronics and a multiplexer. The multiplexer can select one of five probes from either chuck for C-V measurement. DuoChuck Data Sheet: General Description: The Materials Development Corporation DuoChuck Integrated Hot Chuck System combines two microprocessor-based hot chuck controllers, two hot chucks, a multiplexer, and dual programmable stress supplies into one sturdy, solid aluminum dark box. All system operations are controlled by a standard RS-232C serial port. General Specifications and Requirements: POWER: 108 to 125 VAC, 20 Amps, 50 to 60 Hz 208 to 230 VAC option available COOLANT SUPPLY: Tap water at 2 gallons/minute (8 liters/minute) at 15 psi, (1 Bar). Maximum pressure of 20 psi (1.3 Bar). No de-ionized water. VACUUM SUPPLY: 20-25 inches (500-600 mm) Hg. LIGHTS FOR C -V STABILIZATION: 2, computer controlled BIAS VOLTAGE SUPPLY: 2, ±20 V range, 0.1 V resolution DIMENSIONS: Width 25.5" (65 cm); Depth 20.5" (64 cm); Height 9; (23 cm) Temperature Specifications RANGE: Cooling water ambient to 300° C. DISPLAY ACCURACY: ±1°C (15°C to 300°C) OVERTEMPERATURE: Factory set shutdown above 315°C THERMOCOUPLE: Type J (2 required for each chuck) COMMUNICATIONS FORMAT: RS-232C, 8-bit character, 1 stop bit, no parity BAUD RATES: 300, 600, 1200, 2400, 4800, 9600. Hot Chuck Information: MODEL: 8512-8 CHUCK DIAMETERS: 6.6" (165 mm) 8.6" (218 mm) HEATING TIMES: 320 seconds 400 seconds (ambient to 300°C) COOLING TIMES: 225 seconds 500 seconds (300°C to 50°C)
