Mcu 8051demonstration Board,development Kit For 16x2 Character Oled Display

US $55.30

  • Shenzhen, Guangdong, China
  • Feb 27th
Open on mobile:
QR code
  Description The display is a critical component in every project, impacting the case, firmware, electrical design, user interface, and even battery life. For these reasons, and because it is the most visible component of your product, it must be approved by the mechanical design team, management and marketing.Before these teams can approve, they need to see it in action. But it can take days or weeks to connect a graphic display to your platform, initialize it and build a graphic code library able to create believable demonstrations. Meanwhile, the whole project is on hold.Our development kit / demonstration board can solve this problem. Use it to get the display seen, demonstrated and approved for your project. ER-DBOM1602-4 is a microcontroller 8051(80C51) demonstration and development kit for ER-OLEDM1602-4 product that is 16x2 oled character display with US2066 controller ic.The kit includes mcu board controlled by STC89LE52RC that is written graphic and text into it,the crimp tool with flat cable is used to connect mcu board and display module,power supply in 12v. No wiring.No soldering.You'll have it running in under 1 minute!   What's included in the package Num Standard Accessory Name Qty 1 MCU Board 1 2 Crimping Tool 1 3 Power Supply 1 Specification Gross Weight (kg) 0.4000 Manufacturer EastRising Part Number(Order Number) ER-DBOM1602-4 Outline Dimension 150.00x76.00mm Voltage 12v Series Number No Document Format Documents Name (Downloadable) Version Language Update Date Size ER-DBOM1602-4 User Guide 1.0 English Feb-27-2015 358K MCU IC STC89LE52RC Datasheet 1.0 English Jul-25-2011 3.4M MCU Board Schematic Drawing 1.0 English Jan-15-2015 219K Adaptor Board Schematic Drawing 1.0 English Jan-26-2015 114K
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand EastRising
MPN ER-DBOM1602-4
Model ER-DBOM1602-4
Country/Region of Manufacture China
