Meter Transistor Tester Diode Triode Capacitance Scr Inductance Measurement Tool

US $21.35

Shenzhen, China
Jul 30th

Open on mobile:
QR code

Meter Transistor Tester Diode Triode Capacitance SCR Inductance Measurement Tool Item Description Features : 1,2013 latest M328 version of the software ,more functions.Chip: Atmega328 2.128*64 big Backlight LCD display,only 2mA when stand by. 3,Using 9V battery (Not included) Test ranges: Inductors, capacitors , diodes, dual diode , mos, transistor, SCR , the regulator, LED tube , ESR, Resistance,Adjustable potentiometer Resistance :0.1 ohm resolution, maximum 50M ohm Capacitor :25pf -100,000 uf Inductors : 0.01mh-20H Function: 1:Automatic detection of NPN and PNP transistors, n-channel and p-channel MOSFET, diode (including double diode), thyristor, transistor, resistor and capacitor and other components 2: Automatic test the pin of a component, and display on the LCD 3:Can detect the transistor, MOSFET protection diode amplification coefficient and the base to determine the emitter transistor forward biased voltage 4: Measure the gate and gate capacitance of the MOSFET threshold voltage 5:Use 12864 liquid crystal display with green backlight Specifications: For you reference 1,One -button operation, automatic shutdown . 2,Only 20nA shutdown current. 3,Automatically detect NPN, PNP bipolar transistors , N -channel and P -channel MOS FET, JFET , diodes , two diodes, thyristors small power unidirectional and bidirectional thyristor. 4,Automatic identification components pin arrangement . 5,Measuring bipolar transistor current amplification factor and base - emitter threshold voltage. 6,Via the base - emitter threshold voltage and high current amplification factor to identify Darlington transistors. 7,Can detect bipolar transistors and MOS transistors protection diodes. 8,Measuring the gate MOS FET threshold voltage and the gate capacitance. 9,Can simultaneously measure two resistors and resistor symbol is displayed. Displayed on the right with a decimal value of 4 . Resistance symbol on both sides shows the pin number. So you can measure the potentiometer. If the potentiometer wiper is not transferred to an extreme position , we can distinguish the middle and both ends of the pin. 10,Resistance measurement resolution is 0.1 ohms , 50M ohms can be measured . 11,Can measure capacitanceCan measure capacitance of 30pF-100mF , resolution 1pF. 12.2uF more capacitors can simultaneously measure the equivalent series resistance ESR values. The two can be displayed with a decimal value , resolution 0.01 ohms. 13,Can be in the correct order and the diode symbol display two diodes , and gives the diode forward voltage. 14.LED is detected as a diode forward voltage higher . Combo of the LED is identified as two diodes. 15,Eeverse breakdown voltage is less than 4.5V Zener diode can be identified. 16,Can measure a single diode reverse capacitance. If the bipolar transistor connected to the base and collector or emitter of a pin , it can measure the collector or emitter junction reverse capacitance . 18 can be obtained with a single measurement rectifier bridge connection. Notice: Before measuring capacitance , the capacitor must be discharged , otherwise very likely damage the meter .The screen is not fixed Package Included: 1PCS * Mega328 Transistor Tester Diode Triode Capacitance ESR Meter MOS PNP/NPN M328 Payment Please ensure your shipping address on your account is correct. If you have any address change, please inform us on the eBay note. All orders can be canceled until they are shipped. If your order has been paid and you need to change or cancel it, you must contact us within 2 hours. Once the packaging and shipping process has started, it can no longer be canceled. Shipping Once we have received payment, your items will be dispatched in 1-2 days. Delivery time 7-30 days. There may be some delays due to flight, holiday, weather, local post, local natural disaster impact. If your shipment delays or you have not received your order within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Return We offer a 100% money-back guarantee on products that are defective or damaged during shipping. Just contact us with pictures of the damaged items. We will refund the full purchase price of your item and we will send a replacement or refund the full purchase price as preferred. We will refund you for items returned within 30 days of you receiving them, for any reason. To be eligible for a refund, your item must be unused and in the same condition that you received it. Customers will be responsible for paying shipping costs for returning items. It must also be in the original packaging. Before returning items, please contact us. To be eligible for a refund please contact us within 7 days of you receiving the item.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	001
Modified Item	No
MPN	Does not apply
Country/Region of Manufacture	China
Operating Temperature	0 - 40
Product	Impedance/Gain-Phase Analyzer
DIY Supplies	ELECTRICAL
Custom Bundle	No
Brand	Unbranded
