Microchip 12f675-i/sn Sop8 Ship From Us

US $2.57

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

Our mission is to give you the e–components you need without having to deal with long delivery times from China. All of our components are already in the US. You can order 1pcs of any part, there is no minimum for ordering. just place an order and you will have your parts in no time! All components come in brand new condition with a 2 months limited warranty, you have plenty of time replace them if needed. High Performance RISC CPU: • Only 35 instructions to learn - All single cycle instructions except branches • Operating speed: - DC - 20 MHz oscillator/clock input - DC - 200 ns instruction cycle • Interrupt capability • 8-level deep hardware stack • Direct, Indirect, and Relative Addressing modes Special Microcontroller Features: • Internal and external oscillator options - Precision Internal 4 MHz oscillator factory calibrated to ±1% - External Oscillator support for crystals and resonators - 5 µs wake-up from SLEEP, 3.0V, typical • Power saving SLEEP mode • Wide operating voltage range - 2.0V to 5.5V • Industrial and Extended temperature range • Low power Power-on Reset (POR) • Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) • Brown-out Detect (BOD) • Watchdog Timer (WDT) with independent oscillator for reliable operation • Multiplexed MCLR/Input-pin • Interrupt-on-pin change • Individual programmable weak pull-ups • Programmable code protection • High Endurance FLASH/EEPROM Cell - 100,000 write FLASH endurance - 1,000,000 write EEPROM endurance - FLASH/Data EEPROM Retention: > 40 years Low Power Features: • Standby Current: - 1 nA @ 2.0V, typical • Operating Current: - 8.5 µA @ 32 kHz, 2.0V, typical - 100 µA @ 1 MHz, 2.0V, typical • Watchdog Timer Current - 300 nA @ 2.0V, typical • Timer1 oscillator current: - 4 µA @ 32 kHz, 2.0V, typical Peripheral Features: • 6 I/O pins with individual direction control • High current sink/source for direct LED drive • Analog comparator module with: - One analog comparator - Programmable on-chip comparator voltage reference (CVREF) module - Programmable input multiplexing from device inputs - Comparator output is externally accessible • Analog-to-Digital Converter module (PIC12F675): - 10-bit resolution - Programmable 4-channel input - Voltage reference input • Timer0: 8-bit timer/counter with 8-bit programmable prescaler • Enhanced Timer1: - 16-bit timer/counter with prescaler - External Gate Input mode - Option to use OSC1 and OSC2 in LP mode as Timer1 oscillator, if INTOSC mode selected Feedback: Once you have received your item, please leave feedback for us as this will inform us that you have received your items. · Please leave us a positive feedback after you receive your order, we will give you a positive feedback soon. · Your satisfaction is most important for us. If you have a problem or question regarding your transaction, please contact us before leaving any type of feedback. And give us the opportunity to reasonably rectify in a reasonable amount of time, whatever your concern may be. Negative feedback does not solve anything. We are always willing to work things out. If we don’t know about it, we can’t fix it. So feel free to contact us. Thank you very much!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Microchip
MPN	12F675-I/SN
Model	12F675-I/SN SOP8
