Microchip Grid Connected Solar Microinverter Inverter Reference Design 220v

US $29

Chino Hills, California, United States
Jun 23rd

Open on mobile:
QR code

New open box unit, some scuff marks from handling. Scroll down for more details. Terms & conditions All sales are final, sold as is, no warranty, and no guarantee unless indicated otherwise in description. You must do your research on the item, and I will NOT be responsible for particularity, descriptions and/or technical issues or missing parts. My description and title may not be accurate, so do your research. You get what is shown in the main picture, do not assume you get more, email me for more info. Contact me about any issues within 14 days so we can resolve in quickly. You get 14 days to contact me on DOA warranty item, after 14 days, all warranty is void. Only DOA warranty or broken item is returnable. Shipping fee is not refundable. Buyer must pay for return shipping. No refund will be given if the item is not in original condition or if there is sign of abuse. PRODUCTS|APPLICATIONS|DESIGN SUPPORT|TRAINING|SAMPLE AND BUY|ABOUT US|CONTACT US|myMicrochip Login Microchip’s Grid-Connected Solar Microinverter Reference Design Part Number: GRID-CONNECTED-SOLAR-MICROINVERTER Microchip’s Grid-Connected Solar Microinverter Reference Design demonstrates the flexibility and power of SMPS dsPIC® Digital Signal Controllers in Grid-Connected Solar Microinverter systems. This reference design has a maximum output power of 215 Watts and ensures maximum power point tracking for PV panel voltages between 20V to 45V DC. High efficiency was achieved by implementing a novel interleaved active-clamp flyback topology with Zero Voltage Switching (ZVS). This reference design is implemented using a single dsPIC33F “GS” digital-power DSCs from Microchip that provides the full digital control of the power conversion as well as all system management functions. As shown in this reference design the dsPIC33F ‘GS’ devices enable designers to easily and cost effectively develop products using advanced switching techniques / topologies that lower switching losses and improve overall system efficiency. The Grid-Connected Solar Microinverter Reference Design is royalty free when used in accordance with the licensing agreement. Do you want a demonstration? Please contact local sales office in your geography to request a demonstration. Click here to find worldwide network of Sales & Support Features High efficiency: 94.5% @ nominal conditions (230Vac systems) Maximum power point tracking: 99.5% Full digital control Burst mode operation @ low output power Output power de-rating @ low PV panel voltages Protection against various current and voltage faults System Islanding to detect grid failure Specifications Recommended input power: 250W Maximum output power: 215W Maximum input DC voltage: 53V DC Maximum Power Point Tracking voltage: 20V to 45V Output current TDD < 5% Power factor > 0.95 Grid Voltage 230vac Nominal (210Vac – 264Vac) 120Vac Nominal (90Vac – 140Vac) Grid Frequency 50Hz Nominal (47Hz – 53Hz) 60Hz Nominal (59.3Hz – 60.7Hz) Documentation & Software Documents Last Updated Size 120Vac Grid-Connected Solar Microinverter Design Package 8/30/2013 2:20:58 PM 18MB 230Vac Grid-Connected Solar Microinverter Design Package 8/30/2013 2:13:49 PM 18MB
